STLVDS050B Datasheet

  • STLVDS050B

  • HIGH SPEED DIFFERENTIAL LINE DRIVERS AND RECEIVERS

  • 285.07KB

  • STMicroelectronics   STMicroelectronics

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

STLVDS050
HIGH SPEED DIFFERENTIAL LINE
DRIVERS AND RECEIVERS
s
s
s
s
s
s
s
s
s
MEETS OR EXCEED THE REQUIREMENTS
OF ANSI EIA/TIA-644-1995 STANDARD
SIGNALING RATES UP TO 400Mbit/s
BUS TERMINAL ESD EXCEEDS 6KV
OPERATES FROM A SINGLE 3.3V SUPPLY
LOW-VOLTAGE DIFFERENTIAL SIGNALING
WITH TYPICAL OUTPUT VOLTAGE OF
350mV AND A 100鈩?LOAD
PROPAGATION DELAY TIMES:
DRIVER: 2ns (TYP)
RECEIVER: 3ns (TYP)
POWER DISSIPATION AT 200MHz:
DRIVER: 25mW (TYP)
RECEIVER: 60mW (TYP)
LVTTL INPUT LEVELS ARE 5V TOLERANT
RECEIVER HAS OPEN-CIRUIT FAIL-SAFE
SOP
TSSOP
DESCRIPTION
The STLVDS050 is differential line drivers and
receivers that use low-voltage differential
signaling (LVDS) to achieve signaling rate as high
as 400Mbps.
The EIA/TIA-644 standard compliant electrical
interface provides a minimum differential output
voltage magnitude of 247 mV into a 100
鈩?/div>
load
and receipt of 100 mV signals with up to 1 V of
ORDERING CODES
Type
STLVDS050BD
STLVDS050BDR
STLVDS050BTR
Temperature
Range
-40 to 85 擄C
-40 to 85 擄C
-40 to 85 擄C
ground potential difference between a transmitter
and receiver.
The intended application of this device an
signaling technique is for point-to-point baseband
data transmission over controlled impedance
media of approximately 100
鈩?/div>
characteristic
impedance.
The transmission media may be printed-circuit
board traces, backplanes, or cables. (Note: The
ultimate rate and distance of data transfer is
dependent upon the attenuation characteristics of
the media, the noise coupling to the environment,
and other application specific characteristics).
Package
SO-16 (Tube)
SO-16 (Tape & Reel)
TSSOP16 (Tape & Reel)
Comments
50 parts per tube / 20 tube per box
2500 parts per reel
2500 parts per reel
May 2003
1/11
