STGP20NC60V Datasheet

  • STGP20NC60V

  • N-CHANNEL 30A - 600V - TO-220/TO-247 Very Fast PowerMESH IGB...

  • 11頁

  • STMICROELECTRONICS   STMICROELECTRONICS

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

STGP20NC60V
STGW20NC60V
N-CHANNEL 30A - 600V - TO-220/TO-247
Very Fast PowerMESH鈩?IGBT
Table 1: General Features
TYPE
STGP20NC60V
STGW20NC60V
s
s
Figure 1: Package
I
C
@100擄C
30 A
30 A
V
CES
600 V
600 V
V
CE(sat)
(Max)
@25擄C
< 2.5 V
< 2.5 V
s
s
s
s
OFF LOSSES INCLUDE TAIL CURRENT
LOSSES INCLUDE DIODE RECOVERY
ENERGY
HIGH CURRENT CAPABILITY
HIGH FREQUENCY OPERATION UP TO 50
KHz
LOWER C
RES
/ C
IES
RATIO
NEW GENERATION PRODUCTS WITH
TIGHTER PARAMETER DISTRUBUTION
3
1
2
3
2
1
TO-220
TO-247
Weight for TO-220: 1.92gr 鹵 0.01
Weight for TO-247: 4.41gr 鹵 0.01
Max Clip Pressure: 150 N/mm
2
Figure 2: Internal Schematic Diagram
DESCRIPTION
Using the latest high voltage technology based on
a patented strip layout, STMicroelectronics has
designed an advanced family of IGBTs, the Pow-
erMESH
鈩?/div>
IGBTs, with outstanding performances.
The suffix 鈥淰鈥?identifies a family optimized for high
frequency.
APPLICATIONS
HIGH FREQUENCY INVERTERS
s
SMPS and PFC IN BOTH HARD SWITCH AND
RESONANT TOPOLOGIES
s
UPS
s
MOTOR DRIVERS
s
Table 2: Order Codes
SALES TYPE
STGP20NC60V
STGW20NC60V
MARKING
GP20NC60V
GW20NC60V
PACKAGE
TO-220
TO-247
PACKAGING
TUBE
TUBE
Rev. 4
July 2004
1/11

STGP20NC60V 產品屬性

  • STGP20NC60V View All Specifications

  • 50

  • 分離式半導體產品

  • IGBT - 單路

  • PowerMESH™

  • -

  • 600V

  • 2.5V @ 15V，20A

  • 60A

  • 200W

  • 標準型

  • 通孔

  • TO-220-3

  • TO-220AB

  • 管件

  • 497-4355-5
