STGB7NB60HD Datasheet

  • STGB7NB60HD

  • N-CHANNEL 7A - 600V DPAK PowerMESH IGBT

  • 325.27KB

  • 8頁

  • STMICROELECTRONICS   STMICROELECTRONICS

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

廬
STGB7NB60HD
N-CHANNEL 7A - 600V DPAK
PowerMESH鈩?IGBT
TYPE
STGB7NB60HD
s
V
CES
600 V
V
CE(sat)
< 2.8 V
I
C
7A
s
s
s
s
s
s
s
HIGH INPUT IMPEDANCE
(VOLTAGE DRIVEN)
LOW ON-VOLTAGE DROP (V
cesat
)
LOW GATE CHARGE
HIGH CURRENT CAPABILITY
VERY HIGH FREQUENCY OPERATION
OFF LOSSES INCLUDE TAIL CURRENT
CO-PACKAGED WITH TURBOSWITCH鈩?/div>
ANTIPARALLEL DIODE
SURFACE-MOUNTING D
2
PAK (TO-263)
POWER PACKAGE IN TAPE & REEL
(SUFFIX "T4")
3
1
D
2
PAK
TO-263
(Suffix "T4")
DESCRIPTION
Using the latest high voltage technology based
on a patented strip layout, STMicroelectronics
has designed an advanced family of IGBTs, the
PowerMESH鈩?/div>
IGBTs,
with
outstanding
perfomances. The suffix "H" identifies a family
optimized to achieve very low switching times for
high frequency applications (<120kHz).
APPLICATIONS
s
HIGH FREQUENCY MOTOR CONTROLS
s
SMPS AND PFC IN BOTH HARD SWITCH
AND RESONANT TOPOLOGIES
ABSOLUTE MAXIMUM RATINGS
Symbol
V
CES
V
GE
I
C
I
C
I
CM
(鈥?
P
tot
T
stg
T
j
Parameter
Collector-Emitter Voltage (V
GS
= 0)
Gate-Emitter Voltage
Collector Current (continuous) at T
c
= 25 C
Collector Current (continuous) at T
c
= 100
o
C
Collector Current (pulsed)
Total Dissipation at T
c
= 25
o
C
Derating Factor
Storage Temperature
Max. Operating Junction Temperature
o
INTERNAL SCHEMATIC DIAGRAM
Value
600
鹵
20
14
7
56
80
0.64
-65 to 150
150
Unit
V
V
A
A
A
W
W/
o
C
o
o
C
C
(鈥? Pulse width limited by safe operating area
June 1999
1/8
