STGB3NB60HDT4 Datasheet

  • STGB3NB60HDT4

  • N-CHANNEL 3A - 600V TO-220/TO-220FP/D2PAK POWERMESH IGBT

  • 12頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

STGP3NB60HD - STGP3NB60HDFP
STGB3NB60HD
N-CHANNEL 3A - 600V - TO-220/TO-220FP/D
2
PAK
PowerMESH鈩?IGBT
TYPE
STGB3NB60HD
STGP3NB60HD
STGP3NB60HDFP
s
s
s
s
s
s
V
CES
600 V
600 V
600 V
V
CE(sat) (Max)
@25擄C
< 2.8 V
< 2.8 V
< 2.8 V
I
C
(#)
@100擄C
6A
6A
6A
1
2
1
3
2
3
HIGH INPUT IMPEDANCE (VOLTAGE DRIVEN)
LOW GATE CHARGE
HIGH FREQUENCY OPERATION
HIGH CURRENT CAPABILITY
OFF LOSSES INCLUDE TAIL CURRENT
CO-PACKAGED WITH TURBOSWITCH鈩?/div>
ANTIPARALLEL DIODE
TO-220
3
1
TO-220FP
D
2
PAK
INTERNAL SCHEMATIC DIAGRAM
DESCRIPTION
Using the latest high voltage technology based on a
patented strip layout, STMicroelectronics has de-
signed an advanced family of IGBTs, the Power-
MESH鈩?IGBTs, with outstanding perfomances.
The suffix "H" identifies a family optimized for high
frequency applications (up to 50kHz)in order to
achieve very high switching performances (reduced
tfall) mantaining a low voltage drop.
APPLICATIONS
s
HIGH FREQUENCY MOTOR CONTROLS
s
SMPS and PFC IN BOTH HARD SWITCH AND
RESONANT TOPOLOGIES
ORDERING INFORMATION
SALES TYPE
STGB3NB60HDT4
STGP3NB60HD
STGP3NB60HDFP
MARKING
GB3NB60HD
GP3NB60HD
GP3NB60HDFP
PACKAGE
D
2
PAK
TO-220
TO-220FP
PACKAGING
TAPE & REEL
TUBE
TUBE
September 2003
1/12
