STF2NK60Z Datasheet

  • STF2NK60Z

  • Zener-Protected SuperMESH MOSFET

  • 529.39KB

  • 16頁

  • STMICROELECTRONICS   STMICROELECTRONICS

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

STF2NK60Z - STQ2NK60ZR-AP
STP2NK60Z - STD2NK60Z-1
N-CHANNEL 600V - 7.2鈩?- 1.4A TO-220/TO-220FP/TO-92/IPAK
Zener-Protected SuperMESH鈩?MOSFET
Table 1: General Features
TYPE
STF2NK60Z
STQ2NK60ZR-AP
STP2NK60Z
STD2NK60Z-1
s
s
s
s
s
s
Figure 1: Package
I
D
1.4
0.4
1.4
1.4
A
A
A
A
Pw
20
3W
45 W
45 W
8
鈩?/div>
8
鈩?/div>
8
鈩?/div>
8
鈩?/div>
V
DSS
600 V
600 V
600 V
600 V
R
DS(on)
<
<
<
<
3
TYPICAL R
DS
(on) = 7.2
鈩?/div>
EXTREMELY HIGH dv/dt CAPABILITY
ESD IMPROVED CAPABILITY
100% AVALANCHE TESTED
NEW HIGH VOLTAGE BENCHMARK
GATE CHARGE MINIMIZED
TO-92 (Ammopack)
TO-220
1
2
3
2
1
3
1
2
DESCRIPTION
The SuperMESH鈩?series is obtained through an
extreme optimization of ST鈥檚 well established
strip-based PowerMESH鈩?layout. In addition to
pushing on-resistance significantly down, special
care is taken to ensure a very good dv/dt capability
for the most demanding applications. Such series
complements ST full range of high voltage MOS-
FETs including revolutionary MDmesh鈩?products.
IPAK
TO-220FP
Figure 2: Internal Schematic Diagram
APPLICATIONS
s
LOW POWER BATTERY CHARGERS
s
SWITH MODE LOW POWER
SUPPLIES(SMPS)
s
LOW POWER, BALLAST, CFL (COMPACT
FLUORESCENT LAMPS)
Table 2: Order Codes
Part Number
STQ2NK60ZR-AP
STP2NK60Z
STD2NK60Z-1
STF2NK60Z
Marking
Q2NK60ZR
P2NK60Z
D2NK60Z
F2NK60Z
Package
TO-92
TO-220
IPAK
TO-220FP
Packaging
AMMOPAK
TUBE
TUBE
TUBE
Rev. 5
September 2005
1/16

STF2NK60Z 產品屬性

  • 50

  • 分離式半導體產品

  • FET - 單

  • SuperMESH™

  • MOSFET N 通道，金屬氧化物

  • 標準型

  • 600V

  • 1.4A

  • 8 歐姆 @ 700mA，10V

  • 4.5V @ 50µA

  • 10nC @ 10V

  • 170pF @ 25V

  • 20W

  • 通孔

  • TO-220-3 整包

  • TO-220FP

  • 管件

  • 497-12576-5STF2NK60Z-ND
