ST485A

VERY HIGH SPEED

LOW POWER RS-485/RS-422 TRANSCEIVER

s

s

s

s

s

s

s

s

s

s

LOW SUPPLY CURRENT: 5mA MAX

HIGH DATA RATE > 30Mbps

DESIGNED FOR RS 485 INTERFACE

APPLICATIONS

-7 TO 12 COMMON MODE INPUT VOLTAGE

RANGE

DRIVER MANTAINS HIGH IMPEDANCE IN

3-STATE OR WITH THE POWER OFF

70mV TYPICAL INPUT HYSTERESIS

OPERATE FROM SINGLE 5 SUPPLY

鹵4kV ESD PROTECTION

CURRENT LIMITING AND THERMAL

SHUTDOWN FOR DRIVER OVERLOAD

PROTECTION

LATCH-UP FREE UP TO 500mA

DIP

SOP

DESCRIPTION

The ST485A is a low power, high speed

transceiver

for

RS-485

and

RS-422

communications. The device contains one driver

and one receiver in half duplex configuration. The

ST485A draws 3mA (typ.) of supply current when

ORDERING CODES

Type

ST485ACN

ST485ABN

ST485ACD

ST485ABD

ST485ACDR

ST485ABDR

Temperature

Range

0 to 70 擄C

-40 to 85 擄C

0 to 70 擄C

-40 to 85 擄C

0 to 70 擄C

-40 to 85 擄C

Package

unloaded or fully loaded with disabled drivers. It

operates from a single 5V supply.

Driver is short-circuit current limited and is

protected against excessive power dissipation by

thermal shutdown circuitry that place the driver

outputs into a high-impedance state. The receiver

input has a fail-safe feature that guarantees a

logic high output if both inputs are open circuit.

The ST485A is designed for bi-directional data

communications or multipoint bus transmission

lines.

Comments

50parts per tube / 40tube per box

50parts per tube / 40tube per box

100parts per tube / 20tube per box

100parts per tube / 20tube per box

2500 parts per reel

2500 parts per reel

DIP-8

DIP-8

SO-8 (Tube)

SO-8 (Tube)

SO-8 (Tape & Reel)

SO-8 (Tape & Reel)

November 2002

1/13
