ST3232EB

ST3232EC

鹵 15 kV ESD protection 3 to 5.5 V low power,

up to 250 kbps, RS-232 drivers and receivers

Features

鈻?/div>

ESD protection for RS-232 I/O pins

鹵15 kV human body model

鹵8 kV IEC 1000-4-2 contact discharge

300 碌A supply current

250 kbps minimum guaranteed data rate

6V/碌s minimum guaranteed slew rate

Meet EIA/TIA-232 specifications down to 3 V

Available in SO-16, SO-16 large SSOP16 and

TSSOP16

SO-16

SO-16 Large

SSOP16

TSSOP16

Description

The ST3232E is a 3 V powered EIA/TIA-232 and

V.28/V.24 communication interfaces with low

power requirements, high data-rate capabilities

and enhanced electrostatic discharge (ESD)

protection to 鹵 8 kV using IEC1000-4-2 Contact

Discharge and 鹵 15 kV using the Human Body

Model. ST3232E has a proprietary low dropout

transmitter output stage providing true RS-232

performance from 3 to 5 V supplies with a dual

charge pump. The charge pump requires only

four small 0.1 碌F standard external capacitors for

operations from 3 V supply.

The ST3232E has two receivers and two drivers.

The device is guaranteed to run at data rates of

250 kbps while maintaining RS-232 output levels.

Table 1.

Device summary

Temp. range

0 to 70 擄C

-40 to 85 擄C

0 to 70 擄C

-40 to 85 擄C

0 to 70 擄C

-40 to 85 擄C

Packages

SO-16 (tape and reel)

SSOP16 (tape and reel)

TSSOP16 (tape and reel)

Rev 5

Packaging

2500 parts per reel

1350 parts per reel

2500 parts per reel

1/19

www.st.com

Typical applications are Notebook, Subnotebook

and Palmtop Computers, Battery Powered

Equipment, Hand-Held Equipment, Peripherals

and Printers.

Order codes

ST3232ECDR

ST3232EBDR

ST3232ECPR

ST3232EBPR

ST3232ECTR

ST3232EBTR

February 2008
