ST19GF34

Smartcard MCU

With 34 KBytes EEPROM

DATA BRIEFING

ST19GF34 FEATURES:

s

ENHANCED 8 BIT CPU WITH EXTENDED

ADDRESSING MODES

s

s

s

4

4

USER ROM WITH PARTITIONING

56

K BYTES OF

SYSTEM ROM

1984BYTES OF USER RAM WITH

PARTITIONING

34 K BYTES OF USER EEPROM WITH

PARTITIONING

鈥?Highly reliable CMOS EEPROM submicron

technology

鈥?10 years data retention

鈥?100,000 Erase/Write cycles endurance

鈥?Separate Write and Erase cycles for fast "1"

programming

鈥?1 to 64 bytes Erase or Program

鈥?Full support of GSM Toolkit and Javacard im-

plementation

SECURITY FIREWALLS FOR MEMORIES

VERY HIGH SECURITY FEATURES

INCLUDING EEPROM FLASH PROGRAM

8 BIT TIMER WITH INTERRUPT CAPABILITY

2 SERIAL ACCESS, ISO 7816-3 COMPATIBLE

3V

鹵

10% or 5V

鹵

10% SUPPLY VOLTAGE

POWER SAVING STANDBY MODE

CONTACT ASSIGNMENT COMPATIBLE ISO

7816-2

ESD PROTECTION GREATER THAN 5000V

4

4

s

Micromodule (D4)

s

s

Wafer

s

s

s

s

s

s

October 1999

This is Brief Data from STMicroelectronics. Details are subject to change without notice. For complete data, please contact

your nearest Sales Office or SmartCard Products Divison, Rousset, France. Fax: (+33) 4 42 25 87 29

1/2
