ST16ST2G
Smartcard MCU
With up to 16352 Bytes EEPROM & T2G
+
Authentication Library
DATA BRIEFING
s
s
s
s
s
s
8 BIT ARCHITECTURE CPU
15 K Bytes of USER ROM
1 K Byte of T2G
+
AUTHENTICATION LIBRARY
1.5 K Byte of SYSTEM ROM
384 Bytes of RAM
Up to 16352 Bytes of EEPROM, SECTOR
COMBINATIVE
鈥?Highly reliable CMOS EEPROM technology
鈥?10 year data retention
鈥?100,000 Erase/Write cycle endurance
鈥?Protected One Time Programmable block (32
or 64 bytes)
鈥?1 to 32 Byte block Erase or Write in single cy-
cle programming
Micromodule (D3)
3
3
3
3
s
s
SERIAL ACCESS, ISO 7816-3 COMPATIBLE
EXTENDED VOLTAGE OPERATION
鈥?V
CC
Range: 2.7 V to 5.5 V
鈥?I
CC
Operating:4 mA at 5 V (typical)
1.6 mA at 3 V (typical)
s
POWER SAVING STANDBY MODE
鈥?I
CC
Stand-by: 20
碌A(chǔ)
at 5 V (typical)
4
碌A(chǔ)
at 3 V (typical)
Wafer
s
UP TO 5 MHz INTERNAL OPERATING
FREQUENCY
VERY HIGH SECURITY FEATURES
INCLUDING EEPROM FLASH ERASE
CONTACT ASSIGNMENT COMPATIBLE ISO
7816-2
ESD PROTECTION GREATER THAN 5000V
2 OPERATING CONFIGURATIONS
鈥?ISSUER
鈥?USER
T2G
+
SPECIFIC FEATURES
s
AntiClone Function* by France Telecom
s
s
s
FRANCE TELECOM LICENCE
T2G
+
AUTHENTICATION LIBRARY WITH
CBC** (to build Security Module for ST133x and
ST135x ICs)
DEDICATED SOFTWARE TOOLS
T2G
+
Authentication Library
鈥?Emulator with pseudo-ACF*
鈥?Manager with full ACF*
鈥?System ROM Library
s
s
s
s
s
s
MEETS GSM 11.11 AND 11.12
SPECIFICATIONS Contact Name
* AntiClone Function = ACF
** Cipher Block Chaining Mechanism = CBC
October 1999
This is Brief Data from STMicroelectronics. Details are subject to change without notice. For complete data, please contact
your nearest Sales Office or SmartCard Products Divison, Rousset, France. Fax: (+33) 4 42 25 87 29
1/2
