ST16SF42

Smartcard MCU

With 2048 Bytes EEPROM

DATA BRIEFING

s

s

8 BIT ARCHITECTURE CPU

16 KBytes of USER ROM, SECTOR

COMBINATIVE

1.5 KByte of SYSTEM ROM

384 Bytes of RAM

2048 Bytes of EEPROM, SECTOR

COMBINATIVE

鈥?Highly reliable CMOS EEPROM technology

鈥?10 year data retention

鈥?300,000 Erase/Write cycle endurance

鈥?Protected One Time Programmable block (32

or 64 bytes)

鈥?1 to 32 bytes block either Erase or Write in

single cycle programming

Micromodule (D3)

2

2

2

2

s

s

s

s

EXTENDED VOLTAGE OPERATION

鈥?V

CC

Range: 2.7V to 5.5V

SERIAL ACCESS, ISO 7816-3 COMPATIBLE

POWER SAVING STANDBY MODE

UP TO 5 MHz INTERNAL OPERATING

FREQUENCY

VERY HIGH SECURITY FEATURES

INCLUDING EEPROM FLASH ERASE

CONTACT ASSIGNMENT COMPATIBLE ISO

7816-2

ESD PROTECTION GREATER THAN 5000V

MEETS GSM 11.11 AND 11.12

SPECIFICATIONS

2 OPERATING CONFIGURATIONS

鈥?ISSUER

鈥?USER

Wafer

s

s

s

s

s

s

s

s

BD.SF42/9809V4

This is Brief Data from STMicroelectronics. Details are subject to change without notice. For complete data, please contact

your nearest Sales Office or SmartCard Products Divison, Rousset, France. Fax: (+33) 4 42 25 87 29

1/2
