ST10F280
16-BIT MCU WITH MAC UNIT, 512K BYTE FLASH MEMORY AND 18K BYTE RAM
PRODUCT PREVIEW
s
s
s
s
s
s
s
GPT2
s
s
s
HIGH PERFORMANCE CPU WITH DSP FUNCTIONS
- 16-BIT CPU WITH 4-STAGE PIPELINE.
- 50ns INSTRUCTION CYCLE TIME AT 40MHz CPU
CLOCK.
- MULTIPLY/ACCUMULATE UNIT (MAC) 16 X 16-BIT
MULTIPLICATION, 40-BIT ACCUMULATOR
- REPEAT UNIT.
- ENHANCED BOOLEAN BIT MANIPULATION FACILITIES.
- ADDITIONAL INSTRUCTIONS TO SUPPORT HLL
AND OPERATING SYSTEMS.
- SINGLE-CYCLE CONTEXT SWITCHING SUPPORT.
MEMORY ORGANIZATION
- 512K BYTE ON-CHIP FLASH MEMORY SINGLE
VOLTAGE WITH ERASE/PROGRAM CONTROLLER.
- 100K ERASING/PROGRAMMING CYCLES.
- 20 YEAR DATA RETENTION TIME
- UP TO 16M BYTE LINEAR ADDRESS SPACE FOR
CODE AND DATA (5M BYTE WITH CAN).
- 2K BYTE ON-CHIP INTERNAL RAM (IRAM).
- 16K BYTE EXTENSION RAM (XRAM).
FAST AND FLEXIBLE BUS
- PROGRAMMABLE EXTERNAL BUS CHARACTERIS-
TICS FOR DIFFERENT ADDRESS RANGES.
- 8-BIT OR 16-BIT EXTERNAL DATA BUS.
- MULTIPLEXED OR DEMULTIPLEXED EXTERNAL
ADDRESS/DATA BUSES.
- FIVE PROGRAMMABLE CHIP-SELECT SIGNALS.
- HOLD-ACKNOWLEDGE BUS ARBITRATION SUPPORT.
INTERRUPT
- 8-CHANNEL PERIPHERAL EVENT CONTROLLER
FOR SINGLE CYCLE, INTERRUPT DRIVEN DATA
TRANSFER.
- 16-PRIORITY-LEVEL INTERRUPT SYSTEM WITH 56
SOURCES, SAMPLE-RATE DOWN TO 25ns.
TWO MULTI-FUNCTIONAL GENERAL PURPOSE
TIMER UNITS WITH 5 TIMERS.
TWO 16-CHANNEL CAPTURE/COMPARE UNITS
A/D CONVERTER
- 2X16-CHANNEL 10-BIT.
- 4.85碌S CONVERSION TIME
- ONE TIMER FOR ADC CHANNEL INJECTION
8-CHANNEL PWM UNIT
SERIAL CHANNELS
- SYNCHRONOUS/ASYNC SERIAL CHANNEL
- HIGH-SPEED SYNCHRONOUS CHANNEL.
FAIL-SAFE PROTECTION
- PROGRAMMABLE WATCHDOG TIMER.
- OSCILLATOR WATCHDOG.
PBGA208 (23 x 23 x 1.96 - Pitch 1.27 mm)
(Plastic Bold Grid Array)
ORDER CODE:
ST10F280-JT3
s
s
s
TWO CAN 2.0b INTERFACES OPERATING ON ONE
OR TWO CAN BUSSES (30 OR 2X15 MESSAGE
OBJECTS)
ON-CHIP BOOTSTRAP LOADER
CLOCK GENERATION
- ON-CHIP PLL.
- DIRECT OR PRESCALED CLOCK INPUT.
s
UP TO 143 GENERAL PURPOSE I/O LINES
- INDIVIDUALLY PROGRAMMABLE AS INPUT, OUT-
PUT OR SPECIAL FUNCTION.
- PROGRAMMABLE THRESHOLD (HYSTERESIS).
s
s
s
s
s
IDLE AND POWER DOWN MODES
MAXIMUM CPU FREQUENCY 40MHz
PACKAGE PBGA 208 BALLS (23mm x 23mm x
1.96 mm - PITCH 1.27mm).
SINGLE VOLTAGE SUPPLY: 5V 鹵10% (EMBEDDED
REGULATOR FOR 3.3 V CORE SUPPLY).
TEMPERATURE RANGE: -40 +125
擄
C
32
512K Byte
Flash Memory
CPU-Core and MAC Unit
16
16
2K Byte
Internal
RAM
16
16K Byte
XRAM
PEC
16
Watchdog
Oscillator
and PLL
P4.5 CAN1_RxD
P4.6 CAN1_TxD
P4.4 CAN2_RxD
P4.7 CAN2_TxD
CAN1
Interrupt Controller
CAN2
16
XT
AL1
3.3V
XT
AL2
V
oltage
Regulator
Port 4 Port 1 Port 0
GPT1
ASC usart
CAPCOM2
10-Bit ADC
PWM
16
External Bus
Controller
CAPCOM1
SSC
16
Port 2
8
16
8
BRG
Port 3
15
BRG
Port 7
8
Port 8
Port 6
8
Port 5
16
P7.7 T
rigger for ADC
channel injection
XPORT10
16
XPORT9
16
XPWM
4
XTIMER
XADCINJ
External connexion
March 2003
This is advance information on a new product now in development or undergoing evaluation. Details are subject to change without notice.
1/186
