High gain . . . . . . . . . . . . . . . . . . . . . 8.0 dB min @ 1 GHz
鈥?/div>
Low Noise. . . . . . . . . . . . . . . . . . . . . 5.0 dB max @ 1 GHz
(SD202, SD203, SSTSD203)
Low Interelectrode Capacitances
DESCRIPTION
The SD200 series is manufactured utilizing Calogic鈥檚
proprietary DMOS design and processing techniques. The
device is designed to operate well through 1 GHz while
maintaining excellent frequency response, power gain, and
low noise. The DMOS structure is an inherently low
capacitance and very high speed design resulting in a device
that bridges JFETS and GaAs products in performance
characteristics.
ORDERING INFORMATION
Part
SD200DC
SD201DC
SD202DC
SD203DC
SSTSD201
SSTSD203
XSD200
XSD201
XSD202
XSD203
Package
4 Lead TO-52 Package
4 Lead TO-52 Package
4 Lead TO-52 Package
4 Lead TO-52 Package
Surface Mount SOT-143
Surface Mount SOT-143
Sorted Chips in Carriers
Sorted Chips in Carriers
Sorted Chips in Carriers
Sorted Chips in Carriers
SCHEMATIC DIAGRAM
Temperature Range
-55
o
C to +125
o
C
-55
o
C to +125
o
C
-55
o
C to +125
o
C
-55
o
C to +125
o
C
-55
o
C to +125
o
C
-55
o
C to +125
o
C
-55
o
C to +125
o
C
-55
o
C to +125
o
C
-55
o
C to +125
o
C
-55
o
C to +125
o
C
APPLICATIONS
鈥?/div>
High Gain VHF/UHF Amplifiers
鈥?/div>
Oscillators
鈥?/div>
Mixers
PIN CONFIGURATION
(2)
DRAIN
(4)
CASE, BODY
CD10-1
CD10-2
G
D
CASE, B
S
SD201, SD203, zener protected
SD202, SD204, non-zener
(3)
GATE
(1)
SOURCE
GATE (3)
DRAIN (2)
PART MARKINGS (SOT-143)
P/N
MARKING
201
203
BODY INTERNALLY CONNECTED TO CASE.
DIODE PROTECTION ON SD201/SD203 ONLY.
BODY (4)
SOT-143
SOURCE (1)
SSTSD201
SSTSD203
CALOGIC
1
2
