4 Megabit (512K x8) SuperFlash EEPROM
SST28SF040A / SST28VF040A
Data Sheet
FEATURES:
鈥?Single Voltage Read and Write Operations
鈥?5.0V-only for the SST28SF040A
鈥?2.7-3.6V for the SST28VF040A
鈥?Superior Reliability
鈥?Endurance: 100,000 Cycles (typical)
鈥?Greater than 100 years Data Retention
鈥?Memory Organization: 512K x8
鈥?Sector-Erase Capability: 256 Bytes per Sector
鈥?Low Power Consumption
鈥?Active Current: 15 mA (typical) for 5.0V and
10 mA (typical) for 2.7-3.6V
鈥?Standby Current: 5 碌A(chǔ) (typical)
鈥?Fast Sector-Erase/Byte-Program Operation
鈥?Byte-Program Time: 35 碌s (typical)
鈥?Sector-Erase Time: 2 ms (typical)
鈥?Complete Memory Rewrite: 20 sec (typical)
鈥?Fast Read Access Time
鈥?5.0V-only operation: 90 and 120 ns
鈥?2.7-3.6V operation: 150 and 200 ns
鈥?Latched Address and Data
鈥?Hardware and Software Data Protection
鈥?7-Read-Cycle-Sequence Software Data
Protection
鈥?End-of-Write Detection
鈥?Toggle Bit
鈥?Data# Polling
鈥?TTL I/O Compatibility
鈥?JEDEC Standard
鈥?Flash EEPROM Pinouts
鈥?Packages Available
鈥?32-Pin PDIP
鈥?32-Pin PLCC
鈥?32-Pin TSOP (8mm x 14mm and 8mm x 20mm)
storage of program, configuration, or data memory. For all
system applications, the SST28SF040A/28VF040A sig-
nificantly improve performance and reliability, while
lowering power consumption when compared with
floppy diskettes or EPROM approaches. Flash
EEPROM technology makes possible convenient and
economical updating of codes and control programs on-
line. The SST28SF040A/28VF040A improve flexibility,
while lowering the cost of program and configuration
storage application.
The functional block diagram shows the functional
blocks of the SST28SF040A/28VF040A. Figures 1 and
2 show the pin assignments for the 32 pin TSOP, 32 pin
PDIP, and 32 pin PLCC packages. Pin description and
operation modes are described in Tables 1
through 4.
Device Operation
Commands are used to initiate the memory operation
functions of the device. Commands are written to the
device using standard microprocessor write sequences.
A command is written by asserting WE# low while
keeping CE# low. The address bus is latched on the
falling edge of WE# or CE#, whichever occurs last. The
data bus is latched on the rising edge of WE# or CE#,
whichever occurs first. Note, during the Software Data
Protection sequence the addresses are latched on the
rising edge of OE# or CE#, whichever occurs first.
1
2
3
4
5
6
7
PRODUCT DESCRIPTION
The SST28SF040A/28VF040A are 512K x8 bit CMOS
Sector-Erase, Byte-Program EEPROMs. The
SST28SF040A/28VF040A are manufactured using
SST鈥檚 proprietary, high performance CMOS SuperFlash
EEPROM Technology. The split-gate cell design and
thick oxide tunneling injector attain better reliability and
manufacturability compared with alternative ap-
proaches. The SST28SF040A/28VF040A erase and
program with a single power supply. The
SST28SF040A/28VF040A conform to JEDEC standard
pinouts for byte wide memories and are compatible with
existing industry standard flash EEPROM pinouts.
Featuring high performance programming, the
SST28SF040A/28VF040A typically Byte-Program in 35
碌s. The SST28SF040A/28VF040A typically Sector-
Erase in 2 ms. Both Program and Erase times can be
optimized using interface features such as Toggle bit or
Data# Polling to indicate the completion of the Write
cycle. To protect against an inadvertent write, the
SST28SF040A/28VF040A have on chip hardware and
Software Data Protection schemes. Designed, manufac-
tured, and tested for a wide spectrum of applications, the
SST28SF040A/28VF040A are offered with a guaranteed
sector endurance of 10
4
cycles. Data retention is rated
greater than 100 years.
The SST28SF040A/28VF040A are best suited for appli-
cations that require reprogrammable nonvolatile mass
8
9
10
11
12
13
14
15
16
漏 2000 Silicon Storage Technology, Inc. The SST logo and SuperFlash are registered trademarks of Silicon Storage Technology, Inc.
310-3 6/00
1
SSF is a trademark of Silicon Storage Technology, Inc.
These specifications are subject to change without notice.
