SS432G
Adjustable Precision Shunt Regulator
FEATURES
Low voltage operation (1.24V)
Adjustable output voltage from V
O
= V
REF
to 12V
Wide operating current range from 55碌 A to 100mA
Low dynamic output impedance 0.25鈩?typ.
ESD rating is 6kV (per MIL-STD 883D)
DESCRIPTION
The SS432G is a low-voltage three-terminal adjustable shunt
regulator with a guaranteed thermal stability over the applicable
temperature range. The output voltage can be set to any value
between V
REF
(approximately 1.24V) to 12V with two external
resistors (see application circuit). This device has a typical output
impedance of 0.25 ohms. Active output circuitry provides very sharp
turn-on
characteristics,
making
this
device
an
excellent
replacement for Zener diodes in many applications.
The SS432G is characterized for operation from 0擄C to 105擄C,
and three package options (SOT-23, SOT-89, and TO-92) allow
the designer the opportunity to select the proper package for his
application.
Pb-free, RoHS compliant.
APPLICATIONS
Linear Regulators
Adjustable Supplies
Switching Power Supplies
Battery Operated Computers
Instrumentation
Computer Disk Drives
PIN CONFIGURATION
SOT-23 (Top view)
BLOCK DIAGRAM
Cathode
Ref
2
Cathode
Anode
3
1
+
Reference
-
Vref
SOT-89 (Top view)
Anode
3
2
1
Cathode
Anode
Reference
TO-92 (Top view)
3
Cathode
2
Anode
1
Reference
SYMBOL
Cathode
Ref.
Anode
Rev.2.20 7/12/2005
www.SiliconStandard.com
1 of 7
