SS12L
THRU
SS110L
1.0 AMP. Surface Mount Schottky Barrier Rectifiers
Voltage Range
20 to 100 Volts
Current
1.0 Ampere
Features
0.075(1.9)
Sub SMA
0.067(1.7)
Mechanical Data
Cases: Sub SMA plastic case
Polarity: Color band denotes cathode end
Packaging: 12mm tape per EIA STD RS-481
Weight approx. 15mg
A
0.047(1.2)
0.031(0.8)
0.15(3.8)
0.134(3.4)
0.007(0.17)
0.01(0.23)
For surface mounted application
Low 鈥揚(yáng)ROFILE PACKAGE
Ideal for automated placement
Low power loss, high efficiency
High temperature soldering:
260
o
C / 10 seconds at terminals
0.056(1.43)
0.114(2.9)
0.106(2.7)
0.048(1.23)
5
O
5
O
DETAIL "A", SCALE=20/1
Dimensions in inches and (millimeters)
Maximum Ratings and Electrical Characteristics
Rating at 25鈩僡mbient temperature unless otherwise specified.
Single phase, half wave, 60 Hz, resistive or inductive load.
For capacitive load, derate current by 20%
Type Number
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Marking Code (Note 2)
Maximum Average Forward Rectified Current
Peak Forward Surge Current, 8.3 ms Single
Half Sine-wave Superimposed on Rated Load
(JEDEC method )
Maximum Instantaneous Forward Voltage
(Note 1)
@ 0.5A
@ 1.0A
Maximum DC Reverse Current @ T
A
=25鈩?/div>
at Rated DC Blocking Voltage @ T
A
=100鈩?/div>
Maximum Thermal Resistance (Note 3)
Operating Temperature Range
Storage Temperature Range
Symbol
SS
V
RRM
V
RMS
V
DC
I
(AV)
I
FSM
20
SS SS SS SS SS SS Units
12L 13L 14L 15L 16L 19L 110L
30
40
50
60
90
100
V
V
V
A
A
0.65
0.80
0.05
0.5
14
21
28
35
42
63
70
20
30
40
50
60
90
100
12LYM 13LYM 14LYM 15LYM 16LYM 19LYM 10LYM
1.1
30
0.385 0.43 0.51
0.58
0.45 0.50 0.55
0.70
0.4
8.0
6.0
100
45
-55 to +125
-55 to +125
V
F
I
R
R胃
JA
R胃
JL
T
J
T
STG
(0.00~0.10)
0.00~0.004
V
mA
mA
鈩?W
鈩?/div>
鈩?/div>
Notes: 1. Pulse Test with PW=300 usec, 1% Duty Cycle.
2. 12LYM: 1-1A, 2-20V, L-Low Profile, Y-Year Code, M-Month Code
3. Measured on P.C.Board with 0.2 x 0.2鈥?5.0 x 5.0mm) Copper Pad Areas.
- 38 -
