SS12/D Datasheet

  • SS12/D

  • Surface Mount Schottky Power Rectifier

  • 6頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

SS12, SS14
Surface Mount
Schottky Power Rectifier
SMA Power Surface Mount Package
. . . employing the Schottky Barrier principle in a large area
metal鈭抰o鈭抯ilicon power diode. State of the art geometry features
epitaxial construction with oxide passivation and metal overlay
contact. Ideally suited for low voltage, high frequency rectification, or
as free wheeling and polarity diodes in surface mount applications
where compact size and weight are critical to the system.
http://onsemi.com
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Small Compact Surface Mountable Package with J鈭払ent Leads
Rectangular Package for Automated Handling
Highly Stable Oxide Passivated Junction
Guardring for Stress Protection
SCHOTTKY BARRIER
RECTIFIER
1.0 AMPERES
20, 40 VOLTS
Mechanical Characteristics:
鈥?/div>
Case: Epoxy, Molded, Epoxy Meets UL94, VO
鈥?/div>
Weight: 70 mg (approximately)
鈥?/div>
Finish: All External Surfaces Corrosion Resistant and Terminal
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Leads are Readily Solderable
Lead and Mounting Surface Temperature for Soldering Purposes:
260擄C Max. for 10 Seconds
Shipped in 12 mm tape, 5000 units per 13 inch reel
Polarity: Cathode Lead Indicated by Either Notch in Plastic Body or
Polarity Band
Marking: SS12, SS14
Device Meets MSL 1 Requirements
ESD Ratings: Human Body Model, 3B (> 8000 V)
Machine Model, B (> 200 V)
SMA
CASE 403D
PLASTIC
MARKING DIAGRAM
SS1x
SS1
x
= Device Code
= 2 or 4
ORDERING INFORMATION
Device
SS12T3
SS14T3
Package
SMA
SMA
Shipping
鈥?/div>
5000/Tape & Reel
5000/Tape & Reel
鈥燜or information on tape and reel specifications,
including part orientation and tape sizes, please
refer to our Tape and Reel Packaging Specifications
Brochure, BRD8011/D.
漏
Semiconductor Components Industries, LLC, 2003
1
October, 2003 鈭?Rev. 1
Publication Order Number:
SS12/D
