systems
Sensitive receiver for the 2
nd
optical window (1300 nm)
High gain-bandwidth product
Suitable for bit rates up to 1.2 Gbit/s and long-haul
transmission
Planar structure
Small radiant sensitive area
Low multiplied dark current
High spectral sensitivity by built-in optics
Hermetically sealed 3-pin metal case
With optimally coupled multimode-fiber pigtail
Ordering Code
Q62702-Pxxxx
Q62702-Pxxxx
Connector/Flange
Pigtail, FC/PC-connector
Pigtail with flange,
FC/PC-connector
Type
SRD 00514H
SRD 00515H
Component with other connector types on request.
Maximum Ratings
Parameter
Forward current
Reverse voltage
Operating and storage temperature
Max. radiant power into the opt. port
(
V
R
= 5 V)
Soldering time (wave / dip soldering), distance
between solder point and baseplate
(鈮?2 mm, 260 擄C)
* Individual value of
V
BR
is delivered with each component.
Symbol
Values
50
*
鈭?/div>
40
鈥?/div>
+ 85
1
10
Unit
mA
V
擄C
mW
s
I
F
V
R
T
A
T
stg
桅
port
t
s
Semiconductor Group
1
02.95
