SR820
8.0 AMP SCHOTTKY BARRIER RECTIFIERS
THRU
SR860
VOLTAGE RANGE
20 to 60 Volts
CURRENT
FEATURES
* Low forward voltage drop
* High current capability
* High reliability
* High surge current capability
* Epitaxial construction
.412
(10.5)
MAX.
.108
(2.75)
8.0 Amperes
3.8
f
+.2
HOLE THRU
TO-220A
.180
(4.6)
.050
(1.27)
.248
(6.3)
MECHANICAL DATA
* Case: Molded plastic
* Epoxy: UL 94V-0 rate flame retardant
* Lead: Lead solderable per MIL-STD-202,
method 208 guranteed
* Polarity: As Marked
* Mounting position: Any
* Weight: 2.24 grams
.040
(1.0)
MAX.
.051 MAX.
(1.3)
.040 MAX.
(1.0)
.200
(5.08)
+
CASE
.595
(15.1)
MAX.
.550
(14.0)
.158
(4.0) MIN.
MAX.
.120
(3.05)
PIN 1
+
CASE
PIN 2
Case Negative
Suffix "R"
PIN 1
PIN 2
+
Case Positive
Dimensions in inches and (millimeters)
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Rating 25 C ambient temperature uniess otherwies specified.
Single phase half wave, 60Hz, resistive or inductive load.
For capacitive load, derate current by 20%.
TYPE NUMBER
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Rectified Current
See Fig. 1
Peak Forward Surge Current, 8.3 ms single half sine-wave
superimposed on rated load (JEDEC method)
Maximum Instantaneous Forward Voltage at 8.0A
Maximum DC Reverse Current
Ta=25 C
at Rated DC Blocking Voltage
Typical Junction Capacitance (Note1)
Typical Thermal Resistance RqJC (Note 2)
Operating Temperature Range T
J
Storage Temperature Range T
STG
NOTES:
SR820 SR830 SR835 SR840 SR845 SR850 SR860 UNITS
20
30
35
40
45
50
60
V
V
14
21
24
28
31
35
42
V
20
30
35
40
45
50
60
8.0
150
0.65
5.0
50
700
3.0
-65
+125
-65
+150
-65
+150
460
0.75
A
A
V
mA
mA
pF
C/W
C
C
Ta=100 C
1. Measured at 1MHz and applied reverse voltage of 4.0V D.C.
2. Thermal Resistance Junction to Case.
1
2
