Emergency Stop Relay
(Category 4)
SR3C
The SR3C is similar to the SR2C except that it
provides for 3 x 8amp Safety contacts plus one
2amp auxiliar y contact. It is available for use
with a 24VDC supply only.
s
s
s
s
s
s
s
s
s
s
3 safety contacts and 1 auxiliary
Operating voltage 24VDC
Compact housing 22.5mm
Forced guided contacts
Self monitoring with redundancy
Safety gate monitoring
One or two channel emergency stop circuit
Cross short-circuit monitoring
Safety category 4 and stop category 0
Conforms to EN60204-1, VDE113-1, EN954-1
M New
od
els
Guarantee
Year
3
Description
The IMO safety relay SR3C is equipped with force-guided and
redundant relays enabling the SR3C to interrupt quickly and
safely the dangerous parts of the machine.
Additionally each ON/OFF cycle ensures an automatic functional
monitoring, which ensures that if a safety circuit failure occurs
no switching on is possible (self-monitoring).
Applications include one and two channel emergency stop and
two channel safety gate monitoring. A single-fault occurrence
does not lead to the loss of the safety function. It will be
recognised at or before the next requirement of the safety
function. The SR3C satisfies Stop category 0 according to
EN60204-1 and risk category 4 according to EN954-1.
Specifications
Operating voltage
Voltage tolerance
Power consumption
Control voltage on T11
Control current
Contacts
Auxiliar y contacts
Maximum, switching voltage
Switching capacity of contacts
Auxiliar y contact
Minimum current (contacts)
Fuse external (contacts)
Terminals
Contact material
Mechanical life
Electrical ser vice life
Temperature range
Conforms to
24VDC
鹵10%
Approx 1.5W
24VDC
Approx 60mA
3 n/o safety-contacts
1 n/c contact
400VAC, 230VDC
8A, 400VAC, 2000VA AC-12, 1.25A, 24VDC, 30W DC-12
2A, 400V, 500VA, AC-12, 1.25A, 24VDC, 30W DC-12
24V, 200mA
6A
Screw, maximum 2.5mm
2
AgCdO
10 switching operations
7
10
5
switching operations
-15 to +55藲C
VDE0113, part 1/06.93, EN60204-1:1992 EN954-1:1996
