Type
2000/2001
Pan and Tilt Head
Description
Type 2000 & 2001
Innovative design combined with advanced production techniques
and modern styling make the type 2000 the benchmark for the next
generation of pan & tilt heads.
The Type 2000 & 2001 are offered with conventional externally
adjustable limit switches or continuous pan rotation. Pre-postion tell
back options are also available.
Ease of maintenance and servicing has been significantly improved
over conventional pan & tilt designs. All external fixings are the same
size, options and accessories can be retro fitted with plug in wiring.
All Type 2000 pan & tilt heads can be operated upright or inverted
and are also available with d.c. motors.
Features
聦
聧
聨
聫
聬
聭
聮
聯(lián)
聰
Aesthetically styled.
Payloads of upto 20kg (no need for counter balance weights).
Pressure die cast construction.
11.25潞 / sec. pan speed. (available to order)
230V.a.c. 110V.a.c. 24V.a.c. units
Available in a range of configurations
Weatherproof. BS. EN 60529 Level IP 66 (no water ingress)
Covered externally adjustable limits
Anti-backlash pan gearing
Type 2000
The Type 2000 is a 240V.a.c. unit and the Type 2000/110 is a
110V.a.c. unit
Type 2001
The Type 2001 is a 24V.a.c. version of the Type 2000
Build Options
/A
Autopan. (fitted in the unit)
/PP
Pan Potentiometers.
/TP
Tilt Potentiometers.
/PE
Pan Encoder.
/CR
Constant Rotation.
/LT
Low Temperature (-30潞C).
/12擄
Fast Pan Speed.
/SP
Side Platform.
DENNARD SUPPORT LINE +44 (0) 1252 614884
Fax: 01252 626013
