1:2 Demuxed ECL Compatible Outputs
Wide Input Bandwidth - 900 MHz
Low Input Capacitance - 15 pF (MQUAD)
Metastable Errors Reduced to 1 LSB
Monolithic for Low Cost
Gray Code Output
GENERAL DESCRIPTION
The SPT7760 is a full parallel (flash) analog-to-digital con-
verter capable of digitizing full scale (0 to -2 V) inputs into
eight-bit digital words at an update rate of 1 GSPS. The ECL-
compatible outputs are demultiplexed into two separate
output banks, each with differential data ready outputs to
ease the task of data capture. The SPT7760's wide input
bandwidth and low capacitance eliminate the need for exter-
nal track-and-hold amplifiers for most applications. A propri-
CLK CLK
etary decoding scheme reduces metastable errors to the
1 LSB level. The SPT7760 operates from a single -5.2 V
supply, with a nominal power dissipation of 5.5 W.
The SPT7760 is available in an 80L surface-mount MQUAD
package over the industrial temperature range. Contact the
factory for availability of die and /883 versions.
BLOCK DIAGRAM
V
RT
Analog
Input
Preamp
Comparator
256
CLOCK
BUFFER
DEMUX
CLOCK
BUFFER
255
D8
(OVR)
D8B
D7B
鈥?/div>
鈥?/div>
D5B
鈥?/div>
鈥?/div>
D2B
152
256 TO 8 BIT DECODER
WITH METASTABLE ERROR CORRECTION
D7
(MSB)
D6
151
D5
1:2 DEMULTIPLEXER
128
D1B
D0B
D8A
D7A
鈥?/div>
鈥?/div>
鈥?/div>
D5A
鈥?/div>
鈥?/div>
鈥?/div>
D2A
D1A
D0A
V
RM
127
D4
64
D3
63
D2
2
D1
DRB (DATA READY)
DRB (DATA READY)
D8B (OVR)
D7B (MSB)
D6B
D5B
D4B
D3B
D2B
D1B
D0B (LSB)
DRA (DATA READY)
DRA (DATA READY)
D8A (OVR)
D7A (MSB)
D6A
D5A
D4A
D3A
D2A
D1A
D0A (LSB)
1
DO
(LSB)
V
RB
Signal Processing Technologies, Inc.
4755 Forge Road, Colorado Springs, Colorado 80907, USA
Phone: (719) 528-2300 FAX: (719) 528-2370 Website: http://www.spt.com E-Mail: sales@spt.com
ECL OUTPUT BUFFERS AND LATCHES
