SPF MIT3 02

Plastic Fiber Optic Transmitter including Bigfoot

鈩?/div>

IC for MOST

廬

Preliminary Data Sheet

Safety Hints:

Applications of new chip technologies leads to increasing optical efficiency and growing and

higher levels of optical performance. We therefore recommend that the current versions of the

IEC 825-1 and EN 60825-1 standards are taken into account right from the outset, i.e. at the

equipment development stage, and that suitable protection facilities are provided.

The data sheet of the 4-pin MOST Optical Transmitter (MIT3 02) has to be taken as preliminary.

Samples which are delivered before the qualification and the production release are engineering

samples.

Features

Description

The MOST BigfootTx Plastic Fiber Optic Transmitter

Excellent solution for converting high

speed data from TTL to Plastic Optical Fiber

is a highly integrated CMOS IC combined with a High

speed LED designed to transmit up to 25Mbit/sec

(POF)

optical data which is biphase coded at up to

50Mbaud.

鈥?/div>

High speed transmitter up to 50 Mbaud

The internal peaking circuit minimizes PWD.

鈥?/div>

TTL Data Input (Logic to Light Function)

The current through the LED will be setup by an

鈥?/div>

650 nm for working in a low attenuation

external resistor connected to VCC. This makes it

range of PMMA Fiber

鈥?/div>

High coupled power in1000 micron plastic possible to control the optical output power of the

LED.

fiber

鈥?/div>

Low cost

Applications

鈥?/div>

Optical Transmitter for MOST Systems

MOST

MIT3 02

BigfootTx

樓

4: Control

樓

3: Vcc

樓

1: TX_DATA

樓

2: GND

Actual design status:

Bigfoot IC

Revision

package type

CAI

device marking

date code,

MIT3 02

Preliminary Product Information

15-Jan-03

Infineon AG

OASIS SiliconSystems AG

CONFIDENTIAL

Page 1

Data sheet is valid

since

15-Jan-03
