SP8050A Datasheet

  • SP8050A

  • 8 Channel, 150MHz Fully Integrated PDIC Receiver with Gain S...

  • 4頁

  • SIPEX

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

廬
Advanced
SP8050A
8 Channel, 150MHz Fully Integrated PDIC Receiver
with Gain Switching
鈻?/div>
鈻?/div>
鈻?/div>
鈻?/div>
鈻?/div>
鈻?/div>
Data channel bandwidth150MHz
Settling Time: 8ns to 1% for 1.5V step
Three selectable Gain Settings
Group DelayError less than 2ns up to 70MHz
Low Offset Drift of less than 20碌V/
擄C
Low Offset Voltage of less than 10mV
V
REF
SW1
SW2
H+L
G+K
F+J
E+I
GND
1
2
3
4
5
6
7
8
16 V
CC
15 D
SP8050A
16 Pin COB
14 C
13 RF+
12 RF-
11 B
10 A
9 GND
DESCRIPTION
The SP8050A is a high performance 8 channel PDIC with a fully integrated photo detector array
ideally suited for high speed DVDRW, DVDRAM and CDRW systems. Responsivity is fully
specified at wavelengths of 650nm and 780nm. The 8 channels consist of 4 high speed channels
(A, B, C, D) for data detection as well as 4 tracking channels (E, F, G, H) for beam positioning
requirements. Two additional outputs (RF+ and RF-) representing the sums of the high speed
channels are also provided.
The SP8050A is manufactured with an advanced, fully complementary proprietary BiCMOS
process that enables integration of on-board multiple photo detector arrays
V
CC
A
VA
B
VB
C
VC
D
VD
E
I
F
J
G
K
GND
H
L
V (E + I)
V (F + J)
V (G + K)
V (H + L)
VS
BIAS CIRCUIT-1
VRF + (A-D)
SW1 (GAIN)
VA
VB
VC
VD
BIAS CIRCUIT - 1
SW2 (GAIN)
BIAS CIRCUIT - 2
VRF - (A-D)
SP8050A Functional Diagram
Rev. 4/30/03
SP8050A, 8 Channel, 150MHz PDIC Receiver with Gain Switching
漏 Copyright 2003 Sipex Corporation
1
