廬

SP506

5V, Single Chip WAN Multi-Mode Serial Transceiver

鈻?/div>

Interface Modes Supported:

鉁?/div>

X.21/RS-422

(V.11)

鉁?/div>

RS-232

(V.28)

鉁?/div>

EIA-530

(V.10 & V.11)

鉁?/div>

EIA-530A

(V.10 & V.11)

鉁?/div>

RS-449

(V.10 & V.11)

鉁?/div>

V.35

(V.35 & V.28)

鉁?/div>

V.36

(V.10 & V.11)

鉁?/div>

RS-485

(unterminated V.11)

鈻?/div>

Software Selectable Protocol

鈻?/div>

Highest Differential Transmission Rates

at over 20Mbps

鈻?/div>

+5V Only Operation

鈻?/div>

Seven (7) Drivers and Seven (7) Receivers

鈻?/div>

Driver and Receiver Tri-state Control

鈻?/div>

Internal Transceiver Termination Resistors for

V.11 and V.35 Protocols

鈻?/div>

Loopback Self-Test Mode

鈻?/div>

Improved ESD Tolerance for Analog I/Os

鈻?/div>

Compliant to NET1/2 and TBR2 Physical Layer

Requirements

鈻?/div>

Used in WAN Serial Ports in Routers, Switches,

DSU/CSU's and other Access Devices

DESCRIPTION

The

SP506

is a monolithic IC that supports eight (8) popular serial interface standards for DTE

to DCE connectivity. The

SP506

is pin-to-pin compatible to our SP505 multi-protocol transceiver

but with faster throughput. The seven (7) drivers and seven (7) receivers can transmit and receive

signals at 20Mbps. As with the SP505, the

SP506

requires no additional external components

for compliant operation for all of the eight (8) modes of operation. All necessary termination is

integrated within the

SP506

and is switchable when V.35 drivers, V.35 receivers, and V.11

receivers are used. The

SP506

can operate as either a DTE or DCE.

Additional features with the

SP506

include internal loopback that can be initiated in either single-

ended or differential modes. While in loopback mode, driver outputs are internally connected to

receiver inputs creating an internal signal path convenient for diagnostic testing. This eliminates

the need for an external loopback plug. The

SP506

also includes a latch enable pin with the driver

and receiver address decoder. Tri-state ability for the driver and receiver outputs is controlled by

supplying a 4-bit word into the address decoder. Seven (7) drivers and one (1) receiver in the

SP506

include separate enable pins for added convenience.

V.35

EIA-530

WAN

Rev: A Date: 1/27/04

SP506 Multi鈥揗ode Serial Transceiver
