SF10AG - SF10JG
1.0A SUPER-FAST GLASS PASSIVATED RECTIFIER
Features
路
路
路
路
路
路
路
Glass Passivated Die Construction
Diffused Junction
Super-Fast Switching for High Efficiency
High Current Capability and Low Forward
Voltage Drop
Surge Overload Rating to 30A Peak
Low Reverse Leakage Current
Plastic Material: UL Flammability
Classification Rating 94V-0
A
B
A
D
C
Mechanical Data
路
路
路
路
路
路
Case: Molded Plastic
Terminals: Plated Leads Solderable per
MIL-STD-202, Method 208
Polarity: Cathode Band
Marking: Type Number
Weight: 0.3 grams (approx.)
Mounting Position: Any
Dim
A
B
C
D
DO-41
Min
25.40
4.06
0.71
2.00
Max
戮
5.21
0.864
2.72
All Dimensions in mm
Maximum Ratings and Electrical Characteristics
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitive load, derate current by 20%.
Characteristic
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
RMS Reverse Voltage
Average Rectified Output Current
@ T
A
= 75擄C
(Note 1)
Non-Repetitive Peak Forward Surge Current
8.3ms Single half sine-wave Superimposed on Rated Load
(JEDEC Method)
Forward Voltage
Peak Reverse Current
at Rated DC Blocking Voltage
Reverse Recovery Time (Note 3)
Typical Junction Capacitance (Note 2)
Thermal Resistance Junction to Ambient
Operating and Storage Temperature Range
@ I
F
= 1.0A
@ T
A
= 25擄C
@ T
A
= 100擄C
Symbol
V
RRM
V
RWM
V
R
V
R(RMS)
I
O
I
FSM
V
FM
I
RM
t
rr
C
j
R
qJA
T
j,
T
STG
SF10
AG
50
35
@ T
A
= 25擄C unless otherwise specified
SF10
BG
100
70
SF10
CG
150
105
SF10
DG
200
140
SF10
FG
300
210
SF10
GG
400
280
SF10
HG
500
350
SF10
JG
600
420
Unit
V
V
A
A
1.0
30
0.95
10
100
35
75
75
-65 to +150
40
50
50
1.3
1.5
V
mA
ns
pF
K/W
擄C
Notes:
1. Valid provided that leads are maintained at ambient temperature at a distance of 9.5mm from the case.
2. Measured at 1.0MHz and applied reverse voltage of 4.0V DC.
3. Measured with I
F
= 0.5A, I
R
= 1.0A, Irr = 0.25A. (See Figure 5)
DS24012 Rev. A1-2
1 of 2
SF10AG - SF10JG
1
2
