Bulletin I2074/B

SD823C..C SERIES

FAST RECOVERY DIODES

Hockey Puk Version

Features

High power FAST recovery diode series

2.0 to 3.0 碌s recovery time

High voltage ratings up to 2500V

High current capability

Optimized turn on and turn off characteristics

Low forward recovery

Fast and soft reverse recovery

Press-puk encapsulation

Hockey Puk version case style B-43

Maximum junction temperature 150擄C

810A

910A

Typical Applications

Snubber diode for GTO

High voltage free-wheeling diode

Fast recovery rectifier applications

case style B-43

Major Ratings and Characteristics

Parameters

I

F(AV)

@ T

hs

I

F(RMS)

I

FSM

@ 50Hz

@ 60Hz

V

RRM

range

t

rr

@ T

J

T

J

SD823C..C

S20

810

55

1500

9300

9730

Units

A

擄C

A

A

A

V

碌s

擄C

擄C

S30

910

55

1690

9600

10050

1200 to 2500 1200 to 2500

2.0

25

- 40 to 150

3.0

25

D-715
