SD57030-01

RF POWER TRANSISTORS

The

LdmoST

FAMILY

PRELIMINARY DATA

N-CHANNEL ENHANCEMENT-MODE LATERAL

MOSFETs

EXCELLENT THERMAL STABILITY

COMMON SOURCE CONFIGURATION

P

OUT

= 30 W with 13 dB gain @ 945 MHz

BeO FREE PACKAGE

s

s

s

s

DESCRIPTION

The SD57030-01 is a common source N-Channel

enhancement-mode lateral Field-Effect RF power

transistor designed for broadband commercial

and industrial applications at frequencies up to

1.0 GHz. The SD57030-01 is designed for high

gain and broadband performance operating in

common source mode at 28V. It is ideal for base

stations applications requiring high linearity.

M250

epoxy sealed

ORDER CODE

BRANDING

SD57030-01

XSD57030-01

PIN CONNECTION

1. Drain

2. Gate

3.Source

ABSOLUTE MAXIMUM RATINGS

(T

case

= 25

o

C)

Symbol

V

(BR)DSS

V

GS

I

D

P

DI SS

T

j

T

STG

Parameter

Drain Source Voltage

Gate-Source Voltage

Drain Current

Power Dissipation (@ Tc= 70 C)

Max. O perating Junction Temperature

Storage T emperature

o

Value

65

鹵

20

4

74

200

-65 to 150

Uni t

V

V

A

W

o

o

C

C

THERMAL DATA

R

th (j-c)

Junction-Case Thermal Resistance

1.75

o

C/W

January 2000

1/7

next
