SD1020YS Thru SD10100YS
DPAK SURFACE MOUNT SCHOTTKY BARRIER RECTIFIER
VOLTAGE - 20 to 100 Volts CURRENT - 10.0 Amperes
FEATURES
鈥?Plastic package has Underwriters Laboratory Flammability
Classification 94V-O
鈥?For surface mounted applications
鈥?Low profile package
鈥?Built-in strain relief
鈥?Metal to silicon rectifier majority carrier conduction
鈥?Low power loss, High efficiency
鈥?High current capability, low V
F
鈥?High surge capacity
鈥?For use in low voltage high frequency inverters, free wheeling, and
polarity protection applications
鈥?High temperature soldering guaranteed:260擄C/10 seconds at terminals
2
1
3
.032(0.8)
.012(0.3)
.264(6.7)
.248(6.3)
.098(2.5)
.082(2.1)
DPAK / TO-252
4
.063(1.6)
.047(1.2)
.216(5.5)
.200(5.1)
.024(0.6)
.016(0.4)
.106(2.7)
.090(2.3)
.09 .09
(2.3) (2.3)
.071(1.8)
.051(1.3)
MECHANICAL DATA
1
2
4
Case: D PAK/TO-252 molded plastic
Terminals: Solder plated, solderable per MIL-STD-750,Method 2026
Polarity: Color band denotes cathode
Standard packaging: 16mm tape (EIA-481)
Weight: 0.015 ounce, 0.4 gram.
3
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25
o
C ambient temperature unless otherwise specified.
Resistive or inductive load.
SYMBOLS
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Rectified Current
at T
C
=75
o
C
Peak Forward Surge Current
8.3ms single half sine-wave superimposed on
rated load(JEDEC method)
Maximum Instantaneous Forward Voltage at 10.0A
(Note 1)
Maximum DC Reverse Current (Note 1)T
A
=25
o
C
at Rated DC Blocking Voltage
T
A
=100
o
C
Maximum Thermal Resistance (Note 2)
Operating Junction Temperature Range
Storage Temperature Range
V
V
V
RRM
SD1020YS
20
14
20
10.0
SD1030YS
30
21
30
10.0
SD1040YS
40
28
40
10.0
SD1050YS
50
35
50
10.0
SD1060YS
60
42
60
10.0
SD1080YS
80
56
80
10.0
.040(1.0) MIN.
.02(.5)
.225(5.7)
.209(5.3)
SD10100YS
100
70
100
10.0
UNITS
Volts
Volts
Volts
Amps
RMS
DC
I (
AV
)
I
FSM
200
200
200
200
200
200
200
Amps
V
F
0.55
0.2
20
6
80
0.55
0.2
20
6
80
0.55
0.2
20
6
80
0.75
0.2
20
6
80
-55 to +125
-65 to +150
0.75
0.2
20
6
80
0.85
0.2
20
6
80
0.85
0.2
20
6
80
o
Volts
I
R
R胃JC
R胃JA
T
J
T
STG
mA
C/W
o
C
C
o
NOTES:
1. Pulse Test with PW=300碌sec, 2% Duty Cycle.
2. Mounted on P.C. Board with 14mm
2
(.013mm thick) copper pad areas.
Part Number: SD1020YS - SD10100YS
