Ordering number:EN3616A
SB07W03P
Schottky Barrier Diode (Twin Type 路 Cathode Common)
30V, 700mA Rectifier
Applications
路 General rectifier.
路 High frequency rectification (switching regulators,
converters, choppers).
Package Dimensions
unit:mm
1239A
[SB07W03P]
Features
路 Low forward voltage (VF max=0.55V).
路 Fast reverse recovery time (trr max=10ns).
路 Low switching noise.
路 Low leakage current and high reliability due to
highly reliable planar structure.
1:Anode
2:Cathode
3:Anode
Specifications
Absolute Maximum Ratings
at Ta = 25藲C (Value per element)
Parameter
Repetitive Peak Reverse Voltage
Non-repetitive Peak Reverse Surge Voltage
Average Output Current
Surge Forward Current
Junction Temperature
Storage Temperature
Symbol
VRRM
VRSM
IO
IFSM
Tj
Tstg
50Hz sine wave, 1 cycle
Conditions
SANYO:PCP
Ratings
30
35
700
5
鈥?5 to +125
鈥?5 to +125
Unit
V
V
mA
A
藲C
藲C
Electrical Characteristics
at Ta = 25藲C (Value per element)
Parameter
Reverse Voltage
Forward Voltage
Reverse Current
Inter terminal Capacitance
Reverse Recover y Time
Thermal Resistance
Symbol
VR
VF
IR
C
trr
Rthj-a(1)
Rthj-a(2)
IR=300碌A
IF=700mA
VR=15V
VR=10V, f=1MHz
IF=IR=100mA, See specified Test Circuit.
300
28
10
110
Conditions
Ratings
min
30
0.55
50
ty p
max
Unit
V
V
碌A
pF
ns
藲C/W
藲C/W
Mounted on
250mm
2
脳0.8mm
ceramic board
路 Marking:SF
trr Test Circuit
Electrical Connection
1:Anode
2:Cathode
3:Anode
