Ordering number : EN3612A
Schottky Barrier Diode (Twin Type 路 Cathode Common)
SB05W05V
50V, 500mA Rectifier
Applications
鈥?Universal-use rectifier.
鈥?High frequency rectification (switching regulators, converters, choppers).
Features
鈥?Low forward voltage (VF max=0.55V).
鈥?Fast reverse recovery time (trr max=10ns).
鈥?Low switching noise.
鈥?Low leakage current and high reliability due to highly reliable planar structure.
Absolute Maximum Ratings
at Ta=25擄C (Value per element)
Repetitive Peak Reverse Voltage
Nonrepetitive Peak Reverse
Surge Voltage
Average Output Current
Surge Forward Current
Junction Temperature
Storage Temperature
VRRM
VRSM
Io
IFSM
Tj
Tstg
50
55
500
5
鈥?5 to +125
鈥?5 to +125
min
50
typ
unit
V
V
mA
A
擄C
擄C
max
0.55
50
unit
V
V
碌A(chǔ)
pF
ns
擄C/W
50Hz sine wave, 1 cycle
Electrical Characteristics
at Ta=25擄C (Value per element)
Reverse Voltage
Forward Voltage
Reverse Current
Interterminal Capacitance
Reverse Recovery Time
Thermal Resistance
VR
VF
IR
C
trr
Rthj-a
IR=200碌A(chǔ)
IF=500mA
VR=25V
VR=10V, f=1MHz
IF=IR=100mA,
See specified Test Circuit.
25
10
120
trr Test Circuit
Package Dimensions
1148A
(unit : mm)
Erectrical Connection
SANYO Electric Co.,Ltd. Semiconductor Bussiness Headquarters
TOKYO OFFICE Tokyo Bldg., 1-10, 1 Chome, Ueno, Taito-ku, TOKYO, 110 JAPAN
61197GI/N120MH, JK (KOTO) No.3612-1/2
