S6A0079 Datasheet

IC型號：
S6A0079
PDF描述：
34COM/120SEG DRIVER & CONTROLLER FOR DOT MATRIX LCD
文件大?。?/label>
340.56KB
PDF頁數：
36頁
芯片廠家：
SAMSUNG

閱覽下載糾錯 0

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

34COM/120SEG DRIVER & CONTROLLER FOR DOT MATRIX LCD

S6A0079

INTRODUCTION

S6A0079 is a dot matrix LCD driver & controller LSI which is fabricated by low power CMOS technology. It can

display 2, or 4 lines with 5 x 8 dots format.

FUNCTIONS

鈥?/div>

Character type dot matrix LCD driver & controller

鈥?/div>

Internal driver: 34 common and 120 segment signal output

Easy interface with 4-bit or 8-bit MPU

5 x 8 dots matrix possible

Voltage converter for LCD drive voltage: 13V max (2 times/3 times)

Automatic power on reset

FEATURES

鈥?/div>

Internal memory

- Character Generator ROM (CGROM): 9,600 bits (240 characters x 5 x 8 dot)

- Character Generator RAM (CGRAM): 64 x 8 bits (8 characters x 5 x 8 dot)

- Icon RAM (CGRAM): 16 x 8 bits (80 icons max.)

- Display Data RAM (DDRAM): 96 x 8 bits (96 characters max.)

Low power operation

- Power supply voltage range: 2.7

5.5V (VDD)

- LCD Drive voltage range: 3.0

13.0V (VDD - V5)

CMOS process

Duty cycle: 1/33

Internal oscillator with an external resistor

Bare chip available

鈥?/div>

PROGRAMMABLE DUTY CYCLES

5-Dot Font Width

Display Line

Numbers

1/33

Duty Ratio

Single-chip Operation

Displayable Characters

2-line of 48 characters

4-line of 24 characters

Possible Icons
