AUDIO EFFECT PROCESSOR
S5A1901H02
PRODUCT OVERVIEW
OVERVIEW
100鈭扱FP鈭?420C
The S5A1901H02, Audio Effect Processor, reproduces vivid sound of
certain places and dynamic sound of movies. The S5A1901H02 has
over 15 sound effect modes including two kinds of Karaoke mode. In
addition to the sound modes, the S5A1901H02 provides mic-echo,
vocal canceller, loudness function, graphic equalizer, spectrum ana-
lyzer interface, tone control and volume/balance control so that it can
satisfy various sound requirements of audio systems including TV,
stereo audio systems, etc. Furthermore, the S5A1901H02 has built-in
16 bit stereo
危鈭掆垎
ADC and DAC for easy application. The
S5A1901H02 also includes two digital source interface blocks and a
host interface block supporting normal microcontroller and I
2
C bus
interfaces.
KEY FEATURES
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Over 15 Sound Effect Modes including two kinds of Karaoke mode
3/5/7-band Graphic Equalizer and 5/7-band Spectrum Analyzer Interface
Mic-Echo, Loudness Function and Vocal Canceller
Digital Volume/Balance/Tone Control
Fader Function for Car Stereo System
Programmable Sound Mode
33 MIPS 16 bit fixed point DSP Core (SSP1610)
Built-in Stereo 16 bit
危鈭掆垎
ADC and DAC
External Clock: 16.9344MHz
Sampling Frequency: 44.1kHz
Support Various Digital Audio Interface Formats
Normal Microcontroller Interface and I
2
C Bus Interface
0.5 Kword Internal Data RAM and 6 Kword Delay Memory for Sound Effect
6 Kword Internal Program ROM and 0.5 Kword Parameter ROM for Movie Mode
5 V Single Power Supply
0.5碌m Triple Metal CMOS Process
Package: 100 QFP
ORDERING INFORMATION
Device
S5A1901H02-Q0R0 (Audio Effect Processor)
Package
100鈭扱FP鈭?420C
Temperature Range
0擄C
鈭?/div>
70擄C
1
