S560-6600-EK Datasheet

  • S560-6600-EK

  • ADSL Magnetics

  • 81.44KB

  • 2頁

  • BEL   BEL

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

ADSL Magnetics
TM02302
鈥?/div>
Designed to comply with the requirements of UL1950
and EN60950 to provide a supplementary insulation
barrier with a working voltage of 250V
Minimum interwinding breakdown voltage of 1500 Vrms
Minimum interwinding breakdown voltage of 600 Vrms
between pin 9 and 10 for 1 minute
鈥?/div>
鈥?/div>
鈥?/div>
Operating and storage temperature range: -40擄 to +85擄 C
Meets IEC 695, 2-2 flammability requirements
PWB Process Capability: standard printed wiring board
assembly techniques, total-immersion cleaning
Reliability testing: shock, vibration, temperature cycling,
temperature - humidity - bias
鈥?/div>
鈥?/div>
鈥?/div>
ELECTRICAL SPECIFICATIONS AT 25擄 C
Turns Ratio
鹵2%
Part Number
Chip : Line
S560-6600-EK
1 : 2.2
Line Side
800
Inductance
1
碌H 鹵10%
Leakage
Inductance
2
碌H max
Chip Side
5
Chip Side
3.3
DCR
鈩?/div>
max
Line Side
2.5
All measurements are made with pins 2 and 4 connected and pins 1 and 9 connected
1. Inductance measured at 10 kHz, 0.1 Vac
2. Measured at 100 kHz, 0.1 Vac
SCHEMATIC
S560-6600-EK
1
8
3
Line
2
5
IC
7
4
6
漏2002 Bel Fuse Inc. Specifications subject to change without notice. 04.02
Bel Fuse Inc.
206 Van Vorst Street, Jersey City, NJ 07302 鈥?Tel 201-432-0463 鈥?Fax 201-432-9542 鈥?www.belfuse.com
page 1
