SIP REED RELAY
n
S Series
Features
聲
聲
聲
聲
Molded epoxy body
High isolation coil/contact
Can make high voltage contact
Sealed construction permits automatic
flow soldering and cleaning
UL E155513
C-UL E155513
n
Coil Rating
(20擄C)
Contact
Form
Part Number
S1A05000
S1A12000
S1A24000
S1A050D0
S1A120D0
S1A240D0
S1C05M00
S1C12M00
S1C24M00
S1A050X00
S1A120X00
S1A240X00
Nominal
Voltage
(VDC)
5
12
24
5
12
24
5
12
24
5
12
24
Coil
Resistance
(W) 鹵 10%
500
1000
2000
500
1000
2000
500
1000
2000
500
1000
2000
Must
Operate
(VDC)
3.75
9.0
18.00
3.75
9.0
18.00
3.75
9.00
18.00
3.75
9.00
18.00
Must
Rated
Release Current
(VDC)
(mA)
1.0
1.2
2.4
1.0
1.2
2.4
1.0
1.2
2.4
1.0
1.2
2.4
10
12
12
10
12
12
25
24
12
25
24
12
Continous
Voltage
(Max)
10
20
28
10
20
28
10
20
28
10
20
28
Special
Features
standard
standard
standard
with diode
with diode
with diode
magnetic
shield
1A
SPST-NO
1A
SPST-NO
diode +
magnetic
shield
High Resistance Coil for Low Power Consumption 聲 High Effeciency
1A
SPST-NO
SS1A050099
SS1A120098
SS1A120099
5
12
12
1000
2000
3000
3.75
9.00
18.00
1.0
1.2
2.4
5
6
4
10
20
28
standard
standard
standard
