DIGITAL CONTROLLED AUDIO PROCESSOR
S1A0501X01
GENERAL DESCRIPTION
The S1A0501X01 is an audio processor for volume/tone/fader
control, which is suitable for car radios or Hi-Fi system. It has a
built-in trimmer for user to set a source level. R/L rear output is
changable to input in the case of a home audio system for user
conveniency, an external equalizer or a noise reduction circuit
is selectable.
When the S1A0501X01 is used with some sound-effect equip-
ment such as graphic equalizer, the internal tone control block
of S1A0501X01 can be bypassed for decreasing redundancy.
All selections and function controls are designed to be con-
trolled by an I
2
C-bus protocol or a general microprocessor
interface protocol.
32鈭扴OP鈭?50B
#1
FEATURES
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
3-Input multiplexing
Source Level trimmer (selectable input level)
Volume control in 0.6dB step
Tone control (internal bass/treble function block with external components)
Source out / volume in (enable ext.graphic eq./ noise reduction equipment)
Loudness / mute
Fader control ( separated for balance )
All functions are programmable / controllable via serial I
2
C bus
or general Micom interface protocol.
ORDERING INFORMATION
Device
S1A0501X01-S0B0
Package
32鈭扴OP鈭?50B
Operating Temperature
鈭?5擄C
- +75擄C
1
