RX5003 Datasheet

  • RX5003

  • 303.825 MHz Hybrid Receiver

  • 105.49KB

  • 11頁

  • RFM   RFM

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

廬
路
Designed for Short-Range Wireless Control and Data Communications
路
Supports RF Data Transmission Rates Up to 115.2 kbps
路
3 V, Low Current Operation plus Sleep Mode
路
Stable, Easy to Use, Low External Parts Count
The RX5003 hybrid receiver is ideal for short-range wireless control and data applications where
robust operation, small size, low power consumption and low cost are required. The RX5003
employs RFM鈥檚 amplifier-sequenced hybrid (ASH) architecture to achieve this unique blend of
characteristics. All critical RF functions are contained in the hybrid, simplifying and speeding de-
sign-in. The RX5003 is sensitive and stable. A wide dynamic range log detector, in combination
with digital AGC and a compound data slicer, provide robust performance in the presence of
on-channel interference or noise. Two stages of SAW filtering provide excellent receiver out-
of-band rejection. The RX5003 generates virtually no RF emissions, facilitating compliance with
FCC Part 15 and similar regulations.
RX5003
303.825 MHz
Hybrid
Receiver
Absolute Maximum Ratings
Rating
Power Supply and All Input/Output Pins
Non-Operating Case Temperature
Soldering Temperature (10 seconds)
Value
-0.3 to +4.0
-50 to +100
250
Units
V
o
o
C
C
Electrical Characteristics (typical values given for 3.0 Vdc power supply, 25
o
C)
Characteristic
Operating Frequency
Modulation Type
Data Rate
Receiver Performance, High Sensitivity Mode
Sensitivity, 2.4 kbps, 10-3 BER, AM Test Method
Sensitivity, 2.4 kbps, 10-3 BER, Pulse Test Method
Current, 2.4 kbps (R
PR
= 330 K)
Sensitivity, 19.2 kbps, 10-3 BER, AM Test Method
Sensitivity, 19.2 kbps, 10-3 BER, Pulse Test Method
Current, 19.2 kbps (R
PR
= 330 K)
Sensitivity, 115.2 kbps, 10-3 BER, AM Test Method
Sensitivity, 115.2 kbps, 10-3 BER, Pulse Test Method
Current, 115.2 kbps
Receiver Performance, Low Current Mode
Sensitivity, 2.4 kbps, 10-3 BER, AM Test Method
Sensitivity, 2.4 kbps, 10-3 BER, Pulse Test Method
Current, 2.4 kbps (R
PR
= 1100 K)
1
1
2
-104
-98
1.8
dBm
dBm
mA
1
1
2
1
1
2
1
1
-109
-103
3.0
-105
-99
3.1
-101
-95
3.8
dBm
dBm
mA
dBm
dBm
mA
dBm
dBm
mA
Sym
f
O
Notes
Minimum
303.625
OOK/ASK
115.2
kbps
Typical
Maximum
304.025
Units
MHz
1

RX5003 產品屬性

  • 250

  • RF/IF 和 RFID

  • RF 接收器

  • -

  • 303.825MHz

  • -109dBm

  • 115.2kbps

  • ASK，OOK

  • 通用

  • 3.8mA

  • PCB，表面貼裝

  • -

  • PCB，表面貼裝

  • -

  • 2.2 V ~ 3.7 V

  • -40°C ~ 85°C

  • 20-SMD 模塊，無引線

  • SM-20L

  • 帶卷 (TR)
