RURD620, RURD620S
Data Sheet
January 2000
File Number
3640.3
6A, 200V Ultrafast Diodes
The RURD620, and RURD620S are ultrafast diodes with
soft recovery characteristics (t
rr
< 25ns). They have low
forward voltage drop and are silicon nitride passivated
ion-implanted epitaxial planar construction.
These devices are intended for use as
freewheeling/clamping diodes and recti鏗乪rs in a variety of
switching power supplies and other power switching
applications. Their low stored charge and ultrafast soft
recovery minimize ringing and electrical noise in many
power switching circuits, reducing power loss in the
switching transistors.
Formerly developmental type TA49037.
Features
鈥?Ultrafast with Soft Recovery . . . . . . . . . . . . . . . . . . . <25ns
鈥?Operating Temperature. . . . . . . . . . . . . . . . . . . . . . .175
o
C
鈥?Reverse Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . .200V
鈥?Avalanche Energy Rated
鈥?Planar Construction
Applications
鈥?Switching Power Supplies
鈥?Power Switching Circuits
鈥?General Purpose
Ordering Information
PART NUMBER
RURD620
RURD620S
PACKAGE
TO-251
TO-252
BRAND
RUR620
RUR620
Packaging
JEDEC STYLE TO-251
ANODE
CATHODE
CATHODE
(FLANGE)
NOTE: When ordering, use the entire part number. Add the suf鏗亁,
9A, to obtain the TO-252 variant in tape and reel, i.e., RURD620S9A.
Symbol
K
JEDEC STYLE TO-252
CATHODE
(FLANGE)
ANODE
CATHODE
A
Absolute Maximum Ratings
T
C
= 25
o
C Unless Otherwise Speci鏗乪d
RURD620
RURD620S
UNITS
V
V
V
A
A
A
W
mJ
o
C
Peak Repetitive Reverse Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . V
RRM
Working Peak Reverse Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . V
RWM
DC Blocking Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .V
R
Average Recti鏗乪d Forward Current . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . I
F(AV)
T
C
= 160
o
C
Repetitive Peak Surge Current . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . I
FRM
Square Wave, 20kHz
Nonrepetitive Peak Surge Current . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . I
FSM
Halfwave, 1 phase, 60Hz
Maximum Power Dissipation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P
D
Avalanche Energy (See Figures 10 and 11) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E
AVL
Operating and Storage Temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .T
STG
,T
J
Maximum Lead Temperature for Soldering
Leads at 0.063in (1.6mm) from Case for 10s. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . T
L
Package Body for 10s, See Tech Brief 334 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . T
PKG
200
200
200
6
12
60
45
10
-65 to 175
300
260
300
o
C
260
o
C
1
