RSX201L-30
Diodes
Shottky barrier diode
RSX201L-30
Application
High efficient shottky barrier diode.
Rectifier for power supply units.
Battery protection against reversal current
External dimensions
(Unit : mm)
CATHODE MARK
1.5
鹵
0.2
1.2
鹵
0.3
Features
1) Small mold type power diode (PMDS (4526) )
2) High reliability
(ESD resistance typ=22kV (machine model) )
3) Low V
F
/ Low I
R
(V
F
=0.39V at 2A / I
R
=50碌A(chǔ) at 30V)
5 4
1
2
2.6
鹵
0.2
4.5
鹵
0.2
0.1
鹵
0.02
0.1
2.0
鹵
0.2
ROHM : PMDS
EIAJ :
鈭?/div>
1 2 Manufacturing date EX2003.9
JEDEC :
5.0
鹵
0.3
3.9
Structure
Silicon Epitaxial Planer
Absolute maximum ratings
(Ta=25擄C)
Parameter
Reverse voltage (repetitive peak)
Reverse voltage (DC)
Average rectified forward current
Forward peak surge current (60Hz / 1cyc.)
Junction temperature
Storage temperature
Symbol
V
RM
V
R
I
O
I
FSM
Tj
Tstg
Limits
30
30
2
60
150
鈭?0
to 150
Unit
V
V
A
A
擄C
擄C
Electrical characteristics
(Ta=25擄C)
Parameter
Forward voltage
Reverse current
Capacitance between terminals
Electro static discharge resistance
Symbol
V
F
I
R
C
T
ESD
Min.
鈭?/div>
鈭?/div>
鈭?/div>
鈭?/div>
Typ.
0.39
50
120
22
Max.
0.44
150
鈭?/div>
鈭?/div>
Unit
V
碌A(chǔ)
pF
kV
Conditions
I
F
=2A
V
R
=30V
V
R
=10V,
f=1MHz
C=200pF, R=0鈩?1pulse
1/2
