RS201M
THRU
RS207M
SINGLE PHASE 2.0 AMP BRIDGE RECTIFIERS
VOLTAGE RANGE
50 to 1000 Volts
CURRENT
2.0 Amperes
FEATURES
* Ideal for printed circuit board
* Low forward voltage
* Low leakage current
* Polarity: marked on body
* Mounting position: Any
* Weight: 1.52 grams
AC
.580(14.75)
.561(14.25)
RS-2M
.147(3.7)
.130(3.3)
.043(1.1)
.031(0.8)
.417(10.5)
.410(10.2)
+
.058(1.42)
.046(1.17)
.034(.86)
.030(.76)
.09(2.29)
.531(13.5)
.492(12.5)
.027(.70)
.014(.35)
.160(4.05)
SPACING
.140(3.56)
Dimensions in inches and (millimeters)
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Rating 25 C ambient temperature uniess otherwies specified.
Single phase half wave, 60Hz, resistive or inductive load.
For capacitive load, derate current by 20%.
TYPE NUMBER
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Rectified Current
.375"(9.5mm) Lead Length at Ta=85 C
Peak Forward Surge Current, 8.3 ms single half sine-wave
superimposed on rated load (JEDEC method)
Maximum Forward Voltage Drop per Bridge Element at 2.0A D.C.
Maximum DC Reverse Current
Ta=25 C
at Rated DC Blocking Voltage
Operating Temperature Range, T
J
Storage Temperature Range, T
STG
Ta=125 C
RS201M RS202M RS203M RS204M RS205M RS206M RS207M
UNITS
50
35
50
100
70
100
200
140
200
400
280
400
2.0
50
1.1
5
500
-65 +150
-65 +150
600
420
600
800
560
800
1000
700
1000
V
V
V
A
A
V
碌A(chǔ)
碌A(chǔ)
C
C
