鈼?/div>
2:1 Wide Input Voltage Range
3 Watts Regulated Output Power
1.6kVDC Isolation
Also Available with Isolated Outputs,
Output 1/Output 2 (DS) Isolation
Low Profile, 10.2 mm Height
Over Current Protection
Five-Sided Shield
No Derating to 71擄C
Non-Conductive Black Plastic
Standard DIP24 and SMD-Pinning
UL 1950 Component Recognized
High Efficiency to 80%
POWERLINE
DC/DC-Converter
RP03-S_DE
(DE/DS)
Series
3 Watt
DIP24
&
SMD,
Single
&
Dual
Isolated Output
Selection Guide
5V, 12V, 24V and 48V Input Types
Part Number
DIP24 (SMD)
RP03-053.3SE**
RP03-0505SE**
RP03-0512SE**
RP03-0515SE**
RP03-123.3SE**
RP03-1205SE**
RP03-1212SE**
RP03-1215SE**
RP03-243.3SE**
RP03-2405SE**
RP03-2412SE**
RP03-2415SE**
RP03-483.3SE**
RP03-4805SE**
RP03-4812SE**
RP03-4815SE**
RP03-0505DE**
RP03-0512DE**
RP03-0515DE**
RP03-1205DE**
RP03-1212DE**
RP03-1215DE**
RP03-2405DE**
RP03-2412DE**
RP03-2415DE**
RP03-4805DE**
RP03-4812DE**
RP03-4815DE**
Input
Range
VDC
4.5-6
4.5-6
4.5-6
4.5-6
9-18
9-18
9-18
9-18
18-36
18-36
18-36
18-36
36-75
36-75
36-75
36-75
4.5-6
4.5-6
4.5-6
9-18
9-18
9-18
18-36
18-36
18-36
36-75
36-75
36-75
Output
Voltage
VDC
3.3
5
12
15
3.3
5
12
15
3.3
5
12
15
3.3
5
12
15
鹵5
鹵12
鹵15
鹵5
鹵12
鹵15
鹵5
鹵12
鹵15
鹵5
鹵12
鹵15
Output
Current
mA
600
600
250
200
600
600
250
200
600
600
250
200
600
600
250
200
鹵300
鹵125
鹵100
鹵300
鹵125
鹵100
鹵300
鹵125
鹵100
鹵300
鹵125
鹵100
Input
(4)
Current
mA
638
910
845
845
252
352
334
334
126
174
165
165
61
88
84
84
870
845
870
357
334
334
174
167
167
86
84
84
Efficiency
(5)
%
66
70
75
75
70
75
79
79
70
76
80
80
72
75
79
79
73
75
73
74
79
79
76
79
79
77
79
79
Capacitive
(6)
Load max.
碌F
2200
1000
170
110
2200
1000
170
100
2200
1000
170
100
2200
1000
170
100
鹵500
鹵96
鹵47
鹵500
鹵96
鹵47
鹵500
鹵96
鹵47
鹵500
鹵96
鹵47
** add Suffix SMD for SMD package
Description
The E-Series of DC/DC Converters are fully certified to EN 60950: 2000. This makes them ideal for all
Telecom and safety applications where approved isolation is required.
They also meet UL 1950 and CSA 950 standards.
182
April-2005
