RN49A1 Datasheet

  • RN49A1

  • TRANSISTOR | 50V V(BR)CEO | 100MA I(C) | TSOP

  • 212.13KB

  • 5頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

RN49A1
TOSHIBA Transistor
Silicon PNP Epitaxial Type (PCT process) Silicon NPN Epitaxial Type (PCT process)
RN49A1
Switching, Inverter Circuit, Interface Circuit
and Driver Circuit Applications.
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Including two devices in US6 (ultra super mini type with 6 leads)
With built-in bias resistors
Simplify circuit design
Reduce a quantity of parts and manufacturing process
Equivalent Circuit and Bias Resistor Values
Q1
C
R1
R2
R1: 2.2 k鈩?/div>
R2: 47 k鈩?/div>
E
R1
R2
R1: 22 k鈩?/div>
R2: 47 k鈩?/div>
E
Q2
C
B
B
Q1: RN2105F
Q2: RN1108F
Marking
Circuit
(top view)
6
5
4
Equivalent
6
5
4
15
Q1
Q2
1
2
3
1
2
3
961001EAA1
鈥?/div>
TOSHIBA is continually working to improve the quality and the reliability of its products. Nevertheless, semiconductor devices in
general can malfunction or fail due to their inherent electrical sensitivity and vulnerability to physical stress. It is the responsibility of
the buyer, when utilizing TOSHIBA products, to observe standards of safety, and to avoid situations in which a malfunction or failure
of a TOSHIBA product could cause loss of human life, bodily injury or damage to property. In developing your designs, please
ensure that TOSHIBA products are used within specified operating ranges as set forth in the most recent products specifications.
Also, please keep in mind the precautions and conditions set forth in the TOSHIBA Semiconductor Reliability Handbook.
鈥?/div>
The information contained herein is presented only as a guide for the applications of our products. No responsibility is assumed by
TOSHIBA CORPORATION for any infringements of intellectual property or other rights of the third parties which may result from its
use. No license is granted by implication or otherwise under any intellectual property or other rights of TOSHIBA CORPORATION or
others.
鈥?/div>
The information contained herein is subject to change without notice.
2000-04-12
1/5
