RMKD, RMKQ 48
Vishay Thin Film
Hermetic, Dual-In-Line or TO Package Resistor Networks
FEATURES
鈥?High Stability: < 300ppm Max., 2000 hrs., Pn + 70擄C
鈥?Hermetic Cases: Dual-In-Line and TO99
Actual Size
TYPICAL PERFORMANCE
THROUGH HOLE
The superstable RMK nickel-chromium integrated networks
are available in a range of standard designs which bring a
completely new 鈥渟tate-of-the-art鈥?to precision network
performance criteria.
Circuit designers can now incorporate into their circuitry the
ultimate in today鈥檚 performance characteristics as
鈥渟tandards鈥? without needing to call out specially engineered
designs at premium prices.
v
TCR
TOL
ABS
10
ABS
0.05
TRACKING
1
RATIO
0.02
SCHEMATIC
Standard Configuration, Hermetic Case TO99
RMKQ48
7
8
1
R3
R1 R2
R4
6
5
4 Equal and Independent Resistors
4
2
3
Standard Configuration, 8 Leads Hermetic DIL
RMKD 408
RMKD 508
8
7
6
5
8
R2
R1
R2
R3
R1
1
2
3
4
1
2
3
R3
4
7
6
R4
R5
5
Standard Configuration, 16 Leads Hermetic DIL
RMKD86
16
15
14
13
12
11
10
9
R1
R2
R3
R4
R5
R6
R7
R8
4 Equal and Independent
Resistors
Dual Divider Feedback Network
with Equal Value Resistors
1
2
3
4
5
6
7
8
8 Equal and Independent Resistors
Standard Configuration, 14 Leads Hermetic DIL
RMKD714
14
13
12
11
10
9
8
RMKD914
14
R2
13
R4
12
11
R6
10
9
R8
R9
R1
R3
2
3
4
R5
5
6
R7
7
8
R1
R2
R3
R4
R5
R6
R7
1
2
3
4
5
6
7
1
7 Equal and Independent
Resistors
Quad Divider Feedback Network
with Equal Value Resistors
VISHAY THIN FILM 鈥?FRANCE +33.4.93.37.28.24 FAX: +33.4.93.37.27.31 鈥?GERMANY +49.9287.710 FAX: +49 9287.70435 鈥?ISRAEL +972.3.557.0945 FAX: +972.3.558.9121
鈥?ITALY + 39.2.300.11919 FAX: +39.2.300.11999 鈥?JAPAN +81.42.729.0661 FAX: +81.42.729.3400 鈥?SINGAPORE +65.788.6668 FAX: +65.788.0988
鈥?SWEDEN +46.8.594.70590 FAX: +46.8.594.70581 鈥?UK +44 191 514 8237 FAX: +44 1953 457 722 鈥?USA: (610) 407-4800 FAX: (610) 640-9081
www.vishay.com
114
Document Number: 60049
Revision 27-Apr-01
