RL101G THRU RL107G
MINIATURE GLASS PASSIVATED JUNCTION RECTIFIER
Reverse Voltage -
50 to 1000 Volts
Forward Current -
1.0 Ampere
Features
Plastic package has Underwriters Laboratory
Flammability Classification 94V-0 utilizing
Flame Retardant Epoxy Molding Compound
Glass passivated junction version of RL101G
thru RL107G in A-405 package
1.0 ampere operation at T
A
=75 with no
thermal runaway
Mechanical Data
Case:
Molded plastic, A-405
Terminals:
Axial leads, solderable
per MIL-STD-202, method 208
Polarity:
Color band denotes cathode
Mounting Position:
Any
Weight:
0.008 ounce, 0.235 gram
DIM ENSIONS
DIM
A
B
C
D
inches
Min.
0.165
0.079
0.020
1.000
Max.
0.205
0.106
0.024
-
Min.
4.2
2.0
0.5
25.40
mm
Max.
5.2
2.7
0.6
-
Note
Maximum Ratings and Electrical Characteristics
Ratings at 25 ambient temperature unless otherwise specified.
Single phase, half wave, 60Hz, resistive or inductive load.
Symbols
RL
101G
RL
102G
RL
103G
RL
104G
RL
105G
RL
106G
RL
107G
Units
Maximum repetitive peak reverse voltage
Maximum RMS voltage
Maximum DC blocking voltage
Maximum average forward rectified current
0.375" (9.5mm) lead length at T
A
=75
Peak forward surge current, I
FM
(surge):
8.3mS single half sine-wave superimposed
on rated load (MIL-STD-750D 4066 method)
Maximum forward voltage at 1.0A
Maximum DC reverse current
at rated DC blocking voltage
T
A
=25
T
A
=100
V
RRM
V
RMS
V
DC
I
(AV)
I
FSM
V
F
I
R
C
J
R
JA
50
35
50
100
70
100
200
140
200
400
280
400
1.0
30.0
1.1
5.0
100.0
15.0
50.0
-55 to +150
600
420
600
800
560
800
1000
700
1000
Volts
Volts
Volts
Amp
Amps
Volts
A
F
/W
Typical junction capacitance (Note 1)
Typical thermal resistance (Note 2)
Operating and storage temperature range
Notes:
(1) Measured at 1.0MHz and applied reverse voltage of 4.0 VDC
(2) Thermal resistance junction to ambient
T
J
, T
STG
1
1
2
