802.11a WLAN
HiperLAN/2 WLAN
U-NII fixed wireless equipment
12
11
10
GND
1
9
RF OUT/
VCC3
The RFSP5022 power amplifier is a high-
performance GaAs HBT IC designed for use in
transmit applications in the 5.15-5.85 GHz
frequency band. With a P1dB of 25 dBm, the
device is ideal as a final stage for wireless LAN
applications requiring high transmit linearity. The
part demonstrates very low error vector magnitude
(EVM) at the full 54 Mbps data rate for 802.11a.
The input of the PA is matched to 50 ohms and the
output can be easily matched for optimum linearity
and power performance at the desired frequency of
operation between 5.15 and 5.85 GHz. The part
operates off a single +3.3V supply.
VCC2
RF IN
2
Input
Match
VCC1
VCC
8
RF OUT/
VCC3
Product Features
GND
3
Bias
Bias
7
RF OUT/
VCC3
鈥?/div>
鈥?/div>
鈥?/div>
4
VPC1/2
3.00
5
GND
6
VPC3
1.00
0.80
4
0.275
0.225
0.45
0.35
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Functional Block Diagram
25 dBm P1dB@3.3V
23 dB gain
3.0 % EVM @ P
OUT
= +19 dBm
with 54 Mbps OFDM signal
175 mA @ P
OUT
= +19 dBm
with 54 Mbps OFDM signal
Single +3.3V supply voltage
Input matched to 50 ohms
PA power on/off logic
Pin 1
Index Area
12
1. All dimensions are in millimeters, angles in
degrees.
2. The terminal #1 identifier and pad
numbering convention shall conform to
JESD 95-1 SPP-012
3. Lead coplanarity: 0.05 max.
4. Dimension applies to metalized pad and is
measured between 0.25 and 0.30 MM from
pad tip.
1
0.50 TYP
3.00
0.05
1.00
1.80 SQ
Top View
Side View
Bottom View
3x3 mm Package Outline
05/2003
