Preliminary

8

Typical Applications

鈥?Part of 2.4GHz IEEE802.11b WLANs

鈥?Digital Communication Systems

RF2494

HIGH FREQUENCY LNA/MIXER

鈥?WLAN or Wireless Local Loop

鈥?Portable Battery-Powered Equipment

鈥?Spread-Spectrum Communication Systems 鈥?UHF Digital and Analog Receivers

Product Description

The RF2494 is a monolithic integrated UHF receiver front

end suitable for 2.4GHz ISM band applications. The IC

contains all of the required components to implement the

RF functions of the receiver except for the passive filter-

ing and LO generation. It contains an LNA (low-noise

amplifier), a second RF amplifier and a doubly balanced

mixer. The output of the LNA is made available as an out-

put to permit the insertion of a bandpass filter between

the LNA and the RF/Mixer section. The mixer outputs can

be selectively disabled to allow for the IF filter to be used

in the transmit mode.

.80

.65

1.00

0.85

.60

.24 typ

4.00

sq.

.65

.30

4 PLCS

2

.35

.23

1.85

1.55 sq.

12擄

max

.05

.01

.75

.50

.65

.23

.13

4 PLCS

Dimensions in mm.

NOTES:

1

2

Shaded Pin is Lead 1.

Dimension applies to plated terminal and is measured between 0.02 mm and

0.25 mm from terminal end.

8

FRONT-ENDS

3 Pin 1 identifier must exist on top surface of package by identification mark or

feature on the package body. Exact shape and size is optional.

4 Package Warpage: 0.05 max.

5 Die thickness allowable: 0.305 mm max.

Optimum Technology Matching廬 Applied

Package Style: LCC, 16-Pin, 4x4

眉

Si Bi-CMOS

Si BJT

GaAs HBT

SiGe HBT

GaAs MESFET

Si CMOS

Features

鈥?Single 2.7V to 3.6V Power Supply

鈥?2400MHz to 2500MHz Operation

鈥?Two Gain Settings: 28dB or 12dB

鈥?4.5dB Cascaded NF, High Gain Mode

鈥?20mA DC Current Consumption

鈥?Input IP

3

: -23dBm or -8dBm

16

PD 1

VCC1 2

VCC2 3

MIX OUT- 4

5

MIX OUT+

Bias

Circuits

15

GS

14

13

12 NC

LNA

LNA OUT

11 NC

10 MIX IN

9

GND3

LNA IN

VCC4

RF AMP

6

LO IN

7

RX EN

8

VCC3

Ordering Information

RF2494

High Frequency LNA/Mixer

RF2494 PCBA-H Fully Assembled Evaluation Board (2.5GHz)

Functional Block Diagram

RF Micro Devices, Inc.

7628 Thorndike Road

Greensboro, NC 27409, USA

Tel (336) 664 1233

Fax (336) 664 0454

http://www.rfmd.com

Rev A0 010730

8-53
