RF2412

5

Typical Applications

鈥?Digital and Spread-Spectrum Systems

鈥?Analog Communication Systems

鈥?UHF Digital and Analog Transmitters

鈥?GMSK, QPSK, DQPSK, QAM

鈥?Portable Battery-Powered Equipment

鈥?Commercial and Consumer Systems

BROADBAND DUAL-CONVERSION

QUADRATURE MODULATOR

Product Description

The RF2412 is a monolithic integrated transmitter univer-

sal modulation IC capable of generating modulated AM,

PM, or compound carriers in the VHF/UHF frequency

range. The modulation is performed at VHF, then the

resulting spectrum is upconverted to a frequency range

between 100MHz to 1000MHz. The IC contains all of the

required components to implement the modulation func-

tion including differential amplifiers for the baseband

inputs, a LO 90擄 hybrid phase splitter, limiting LO amplifi-

ers, two balanced mixers, a combining differential ampli-

fier, a second upconvert balanced mixer, and an output

RF amplifier which will drive a 50鈩?load. Since the modu-

lation is performed at a low frequency, excellent ampli-

tude balance and phase accuracy are obtained.

Optimum Technology Matching廬 Applied

Si BJT

Si Bi-CMOS

GaAs HBT

SiGe HBT

Si CMOS

1

.299

.292

.009

.005

.018

.014

5

MODULATORS AND

UPCONVERTERS

.092

.493

.486

.050

8 擄MAX

0擄MIN

.413

.398

.050

.016

.010

.008

眉

GaAs MESFET

20 RF OUT

Package Style: SOP-20

Features

鈥?Single 3V to 6V Power Supply

鈥?Digitally-Controlled Power Down Mode

鈥?Dual Conversion

鈥?DC to 50MHz Modulation Frequency

鈥?50MHz to 150MHz IF Frequency

鈥?100MHz to 1000MHz RF Frequency

VDD2 1

VDD1 2

PD 3

I SIG 4

I REF 5

POWER

CONTROL

19 GND

18 GND

17 LO2

16 GND

危

Q REF 6

Q SIG 7

GND 8

GND 9

LO1 10

-45擄

+45擄

15 MIX IN+

14 MIX IN-

13 GND

12 MOD OUT-

11 MOD OUT+

Ordering Information

RF2412

RF2412 PCBA

Broadband Dual-Conversion Quadrature Modulator

Fully Assembled Evaluation Board

Functional Block Diagram

RF Micro Devices, Inc.

7625 Thorndike Road

Greensboro, NC 27409, USA

Tel (336) 664 1233

Fax (336) 664 0454

http://www.rfmd.com

Rev B1 010329

5-7
