RF106 900 MHz Power Amplifier
Product Description
The RF106 is a class AB RF power amplifier for 900 MHz
ISM band applications. It delivers output power
proportional to the input signal power.
The RF106 power amplifier, combined with Conexant's
RF105 diSSTance鈩?(digital Spread Spectrum
Technology) transceiver, forms a complete system
solution for a direct conversion 900 MHz diSSTance radio
which is fully compliant with FCC Part 15 regulations in
the ISM band.
The RF106 is operational in the 900 MHz ISM band with
supply voltage ranging from 2.7V to 5V. It is available in a
small 20-pin TSSOP package, shown in Figure 1. Figure 2
shows a block diagram for the RF106.
Features
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Class AB-type RF power amplifier
100 mW peak envelope output power
Very fast settling from standby mode to active
mode
Efficient high output power operation
Very few external components required
20-pin TSSOP package
Applications
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
diSSTance-technology cordless telephone
Direct sequence spread spectrum systems
Frequency hopping spread spectrum systems
Wireless LANs
Wireless modems
Wireless security
Inventory control systems
RFOUT
GND1
MATCH
VCC1
NC
VCC2
NC
VCC3
GND2
ENABLE
1
2
3
4
5
6
7
8
9
10
RF106
20
19
18
17
16
15
14
13
12
11
GND9
GND8
GND7
GND6
NC
NC
GND5
GND4
GND3
RFIN
Figure 1. RF106 Pin Signals 鈥?20 Pin TSSOP
RFIN
A1
A2
A3
RFOUT
ENABLE
Bias
Figure 2. RF106 Block Diagram
Data Sheet
2/1/99
Order No. W118
