M61529FP
Audio Signal Processor with Surround
REJ03F0010-0100Z
Rev.1.00
Sep.04.2003
Description
M61529FP is the semiconductor integrated circuit for Home Audio. M61529FP includes 2ch electronic volume,
Tone control, 4 Input Selector, Bass Boost, REC output and Mic Mixing. This IC is suitable for Mini Component.
A difference in M61529FP and M61519FP has just changed Tone Input ATT from 0/鈥?3dB to 0/鈥?.2dB.
Features
鈥?/div>
2ch Master Volume (L,R Independent Control)
Main Volume : 0dB to 鈥?6dB (2dB or 4dB step), 鈥撯垶
Trim Volume : 0dB to 鈥?5dB (1dB step)
*Total level is fixed at 鈥?7dB, on condition that the total level of Trim and Master volume is under 鈥溾€?7dB鈥?
鈥?/div>
Tone Control (Bass/Mid/Treble)
鹵8dB
(2dB step)
鈥?/div>
4 Input Selector with Mute
鈥?/div>
Surround Function
鈥?/div>
Vocal Cut Function
鈥?/div>
Bass Boost Function
鈥?/div>
L+R Output for Spectrum Analysis Display
鈥?/div>
L+R Output for Subwoofer
鈥?/div>
MIC Mixing Function
鈥?/div>
2 REC output with mute
鈥?/div>
Input ATT
: 鈥?/0/+3.5dB
鈥?/div>
Tone Input ATT
: 0/鈥?.2dB
鈥?/div>
External Input ATT
: +3/0/鈥?/鈥?dB
Application
Mini/Micro Component, Radio-Cassette Recorder with CD Player, etc.
Recommended Operating Conditions
Supply voltage range鈥︹€︹€︹€︹€︹€︹€︹€?.0 to 10.0V
Recommended supply voltage鈥︹€︹€︹€︹€?..鈥?..9.0V
Rev.1.00, Sep.04.2003, page 1 of 23
