REF05
+5V Precision
VOLTAGE REFERENCE
(Guaranteed Long-Term Stability)
FEATURES
q
OUTPUT VOLTAGE: +5V
鹵
0.1% max
q
GUARANTEED LONG-TERM STABILITY:
25ppm/1000 hrs max
q
EXCELLENT TEMPERATURE STABILITY:
8.5ppm/
擄
C max (鈥?5
擄
C to +125
擄
C)
q
LOW NOISE: 10
碌
Vp-p typ (0.1Hz to 10Hz)
q
EXCELLENT LINE REGULATION:
0.008%/V max
q
EXCELLENT LOAD REGULATION:
0.005%/mA max
q
LOW SUPPLY CURRENT: 1.4mA max
q
SHORT-CIRCUIT PROTECTED
q
WIDE SUPPLY RANGE: 8VDC to 40VDC
q
HIGH LOAD DRIVING CAPACITY: 20mA
q
PACKAGE: Hermetic TO-99
100
80
LONG TERM DRIFT OF THE AVERAGE OF 30 DEVICES
DESCRIPTION
The REF05 is a precision 5V voltage reference. The
drift is laser trimmed to 8.5ppm/擄C max over the
extended industrial and military temperature range.
The REF05 provides a stable 5V output that can be
externally adjusted over a
鹵6%
range with minimal
effect on temperature stability. REF05 operates from a
single supply with an input range of 8V to 40V with a
very low current drain of 1mA, and excellent tempera-
ture stability due to an improved design. Excellent line
and load regulation, low noise, low power, and low
cost make the REF05 the best choice whenever a 5V
voltage reference is required. The REF05 is an ideal
choice for portable instrumentation, temperature trans-
ducers, A/D and D/A converters, and digital voltmeter.
REF05 Drift Over Time (ppm)
APPLICATIONS
q
PRECISION REGULATORS
q
CONSTANT CURRENT SOURCE/SINK
q
DIGITAL VOLTMETERS
q
A/D AND D/A CONVERTERS
q
PRECISION CALIBRATION STANDARD
q
TEST EQUIPMENT
60
40
20
0
鈥?0
鈥?0
鈥?0
鈥?0
鈥?00
0
20
40
60
80
100
120
140
160
180
Time (Days)
