1鈥?x 2鈥?/div>
REC8-XX05SRWL
REC8-XX09SRWL
REC8-XX12SRWL
REC8-XX15SRWL
REC8-XX05DRWL
REC8-XX09DRWL
REC8-XX12DRWL
REC8-XX15DRWL
XX = 9-18Vin = 12
XX =18-36Vin = 24
XX =36-72Vin = 48
Input
Voltage
(VDC)
9-18, 18-36, 36-72
9-18, 18-36, 36-72
9-18, 18-36, 36-72
9-18, 18-36, 36-72
9-18, 18-36, 36-72
9-18, 18-36, 36-72
9-18, 18-36, 36-72
9-18, 18-36, 36-72
Output
Voltage
(VDC)
5
9
12
15
鹵5
鹵09
鹵12
鹵15
Output
Current
(mA)
1600
888
670
533
鹵800
鹵444
鹵335
鹵267
Efficiency
(%)
75
82
82
83
77
82
82
83
Specifications (Core Operating Area) and Operating Temperature / Derating-Graph
Voltage Setting Accuracy
Temperature Coefficient
Ripple and Noise (20MHz BW)
Line Regulation (HL-LL)
Load Regulation (Rated Load to no Load)
Voltage Stability (24 Hrs)
Short Circuit Protection
Cooling
Input Filter
Efficiency
Isolation Voltage (Tested for 60 Seconds)
Isolation Resistance
Switching Frequency at Full Load
Operating Temperature
Storage Temperature
Case Material
鹵1% max.
鹵0.02%/擄C
100mVp-p max.
0.2% max.
Output Power (Watts)
16.0
12.0
8.0
4.0
0
75 100 125
70 90
Operating Temperature 藲C
-25
0
25
50
Safe Operating Area
0.5% max.
鹵0.05%
Continuous
Free-Air Convection
Pi Network
70% min.
1.000VDC min.
10
9
ohms min.
50kHz min.
-25擄C to +70擄C (see Graph)
-40擄C to +100擄C
Metal Case
www.recom-international.com
August 2002
EC 83
